WABCO 4801062040 Electronic Brake Control Module - EBS Axle Modulator 2 Channel, Gen4

WABCO 4801062040 Electronic Brake Control Module - EBS Axle Modulator 2 Channel, Gen4

Name: WABCO 4801062040 Electronic Brake Control Module - EBS Axle Modulator 2 Channel, Gen4
SKU: 4801062040
Price: 1558.99 USD
Availability: InStock

★★★★★ (0)

WABCO 4801062040 Electronic Brake Control Module Electronic Brake Control Module - EBS Axle Modulator 2 Channel, Gen4

Tap to view 3 more

$1,558.99

Limited Availability

Due to limited availability, we will confirm your order and notify you within 1 business day.

30-day Return Policy On eligible items Details

Free Ground shipping on orders over $499 details

WABCO 4801062040 Part Description

Manufacturer

WABCO

EBS Axle Modulator - 2-Channel, Gen 4

WABCO 4801062040 Specifications

Product Attributes

Voltage	24 V
Mounting	2x M12 x 1.5
Distance Between Holes	100 mm
Calculated Volume (dm³)	6.204
Weight	6.867
Port thread 3	Integrated Silencer
Port thread 12	M22 x 1.5 JED - 388-4
Port thread 21	M22 x 1.5 JED - 388-4
Max. operating pressure	13.0 bar
Rated current	10500 mA
Size	235 x 160 x 165
Max. operating pressure	188.5 psi
Temperature Range	-40°C to +80°C
Protection class	IP 6K6K / IP 6K9K
Port thread 22	M22 x 1.5 JED - 388-4
Port thread 4	M16 x 1.5 JED - 388-4
Port thread 11	M22 x 1.5 JED - 388-4

WABCO 4801062040 Customer Reviews

No reviews yet

Be the first to review this product!

WABCO 4801062040 Manufacturer Information

Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
