TrakMotive TO-8030 - CV Axle Shaft
- Part Number
- TO-8030
- Manufacturer
- TRAKMOTIVE
- Description
-
CV Axle Shaft
details
$4999
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
TRAKMOTIVE part description
Product Description
CV Axle Shaft
Product Attributes
| ABS Ring Tooth Count | 48 |
| ABS Ring Type | Toothed |
| Abs Tone Ring Included | Yes |
| Axle Bolt Hex Size (mm) | N/A |
| Axle Bolt Length (mm) | N/A |
| Axle Bolt Thread Size | N/A |
| Axle Nut Head Type | Hex |
| Axle Nut Height (in) | .83 |
| Axle Nut Height (mm) | 21 |
| Axle Nut Hex Size (in) | 1.17 |
| Axle Nut Hex Size (mm) | 30 |
| Axle Nut Included | Yes |
| Axle Nut Length (in) | 1.33 |
| Axle Nut Length (mm) | 35 |
| Axle Nut Locking Type | Cotter Pin |
| Axle Nut Thread Size | M22x1.5 |
| Boot Material | Neoprene |
| Inboard Bolt Head Size (in) | .33 |
| Inboard Bolt Head Size (mm) | 8 |
| Inboard Bolt Head Type | Allen |
| Inboard Bolt Length (in) | 2.17 |
| Inboard Bolt Length (mm) | 55 |
| Inboard Bolt Thread Size | M10x1.5 |
| Inboard Joint Type | Bolt-On |
| Inboard Shaft Connection Style | Bolt-On |
| New Or Remanufactured | New |
| Number of Bolt Holes | 0 |
| Number Of Inboard Joint Bolt Holes | 6 |
| Number Of Inboard Shaft Bolts | 6 |
| Number Of Inboard Splines | 0 |
| Number Of Outboard Joint Bolt Holes | 0 |
| Number Of Outboard Shaft Bolts | 0 |
| Number Of Outboard Splines | 26 |
| Outboard Bolt Head Size (in) | N/A |
| Outboard Bolt Head Size (mm) | N/A |
| Outboard Bolt Head Type | N/A |
| Outboard Bolt Length (in) | N/A |
| Outboard Bolt Length (mm) | N/A |
| Outboard Joint Bolt Thread Size | N/A |
| Outboard Joint Type | Conventional |
| Outboard Shaft Connection Style | Conventional |
| Overall Compressed Length (in) | 20.2 |
| Overall Compressed Length (mm) | 513 |
| Axle Nut Socket Size | 30 |
| Grade Type | Premium |
| Inboard Joint Boot Material | Neoprene |
| Outboard Joint Boot Material | Neoprene |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708508500 |
| UPC | 00844084080301 |
Part Interchanges
- ARC 80-3725
- EMPI 80-6114
- Car Components Technologies (CCT) 7409
- Car Components Technologies (CCT) 7423
- Carquest 410828
- Carquest 800828
- USA Industries 706631
- USA Industries AX-27489
- Prestige Autotech 2125
- Prestige Autotech 2126
- Diversified Shafts Solutions 541N
- Drive Tech America TO-8728
- Drive Tech America TO-8728A
- CARDONE Reman 60-5003
- CARDONE Reman 60-5031
- CARDONE Reman 66-5003
- CARDONE Reman MP5003
- IMC 40751003
- OEM Part Number 4341032091
- OEM Part Number 4341032092
- OEM Part Number 4341032093
- OEM Part Number 4341032140
- OEM Part Number 4342032071
- OEM Part Number 4342032072
- OEM Part Number 4342032073
- Altrom Group 652404
- ODM TO-8-8515A
- TrakMotive TO-8030
- ProTech TO20505
- 410828
- 80-3725
- NCV69511
- 90900
- MX-18728
- 329030
Fits Vehicles
- Toyota Celica (1988-1993)
- Toyota Camry (1988-1991)
- Lexus ES250 (1990-1991)
