(888) 312-8812 Login SignupTRAKMOTIVE NI-8034 CV Axle Shaft
Tap to view 1 more
MSRP: $100.99
$6999
Save $31.00
Limited availability at this price!
In Stock
Get it by Wednesday, Dec 17
TRAKMOTIVE NI-8034 Part Description
TRAKMOTIVE NI-8034 Specifications
Product Attributes
| ABS Ring Tooth Count | 46 |
| ABS Ring Type | Toothed |
| Abs Tone Ring Included | Yes |
| Axle Bolt Hex Size (mm) | N/A |
| Axle Bolt Length (mm) | N/A |
| Axle Bolt Thread Size | N/A |
| Axle Nut Head Type | Hex |
| Axle Nut Height (in) | .71 |
| Axle Nut Height (mm) | 18 |
| Axle Nut Hex Size (in) | 1.375 |
| Axle Nut Hex Size (mm) | 35 |
| Axle Nut Included | Yes |
| Axle Nut Length (in) | 1.57 |
| Axle Nut Length (mm) | 40 |
| Axle Nut Locking Type | Standard |
| Axle Nut Thread Size | M24x1.5 |
| Boot Material | Neoprene |
| Inboard Bolt Head Size (in) | N/A |
| Inboard Bolt Head Size (mm) | N/A |
| Inboard Bolt Head Type | N/A |
| Inboard Bolt Length (in) | N/A |
| Inboard Bolt Length (mm) | N/A |
| Inboard Bolt Thread Size | N/A |
| Inboard Joint Type | Male |
| Inboard Shaft Connection Style | Male |
| New Or Remanufactured | New |
| Number of Bolt Holes | 0 |
| Number Of Inboard Joint Bolt Holes | 0 |
| Number Of Inboard Shaft Bolts | 0 |
| Number Of Inboard Splines | 29, 31 |
| Number Of Outboard Joint Bolt Holes | 0 |
| Number Of Outboard Shaft Bolts | 0 |
| Number Of Outboard Splines | 29 |
| Outboard Bolt Head Size (in) | N/A |
| Outboard Bolt Head Size (mm) | N/A |
| Outboard Bolt Head Type | N/A |
| Outboard Bolt Length (in) | N/A |
| Outboard Bolt Length (mm) | N/A |
| Outboard Joint Bolt Thread Size | N/A |
| Outboard Joint Type | Conventional |
| Outboard Shaft Connection Style | Conventional |
| Overall Compressed Length (in) | 25.47 |
| Overall Compressed Length (mm) | 647 |
| Axle Nut Socket Size | 35 |
| Grade Type | Premium |
| Inboard Joint Boot Material | Neoprene |
| Outboard Joint Boot Material | Neoprene |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708508500 |
| UPC | 00844084070340 |
TRAKMOTIVE NI-8034 Part Interchanges
| Brand | Part Number |
|---|---|
| ARC | 80-5416 |
| EMPI | 80-4598 |
| Car Components Technologies (CCT) | 9773 |
| Mevotech | CV3366 |
| Carquest | 410516, 800516 |
| USA Industries | 708672, AX-8669, AX-8672 |
| American Remanufactured | 40-18331S |
| Diversified Shafts Solutions | 8003N |
| Drive Tech America | NI-8331A |
| Fenwick | CV1672 |
| CARDONE Reman | 60-6155, 60-6157, 66-6157 |
| OEM Part Number | 3910131U01, 3910131U11 |
| Altrom Group | 650732 |
| ODM | NI-8-8638A |
| TrakMotive | NI-8034 |
| ProTech | NI20512 |
| N/A | 410516, NCV53567, 93509, MX-18331S, 259034 |
TRAKMOTIVE NI-8034 Fits Vehicles
- Nissan Maxima (1995-1999)
- INFINITI I30 (1996-1999)
