TrakMotive GM-8082 - CV Axle Shaft
- Part Number
- GM-8082
- Manufacturer
- TRAKMOTIVE
- Description
-
CV Axle Shaft
details
$4349
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
TRAKMOTIVE part description
Product Description
CV Axle Shaft
Product Attributes
| ABS Ring Tooth Count | 0 |
| ABS Ring Type | N/A |
| Abs Tone Ring Included | No |
| Axle Bolt Hex Size (mm) | N/A |
| Axle Bolt Length (mm) | N/A |
| Axle Bolt Thread Size | N/A |
| Axle Nut Head Type | Hex |
| Axle Nut Height (in) | 1.11 |
| Axle Nut Height (mm) | 28 |
| Axle Nut Hex Size (in) | 1.67 |
| Axle Nut Hex Size (mm) | 30 |
| Axle Nut Included | Yes |
| Axle Nut Length (in) | 1.33 |
| Axle Nut Length (mm) | 35 |
| Axle Nut Locking Type | Stake |
| Axle Nut Thread Size | M20x1 |
| Boot Material | Neoprene |
| Inboard Bolt Head Size (in) | N/A |
| Inboard Bolt Head Size (mm) | N/A |
| Inboard Bolt Head Type | N/A |
| Inboard Bolt Length (in) | N/A |
| Inboard Bolt Length (mm) | N/A |
| Inboard Bolt Thread Size | N/A |
| Inboard Joint Type | Male |
| Inboard Shaft Connection Style | Male |
| New Or Remanufactured | New |
| Number of Bolt Holes | 0 |
| Number Of Inboard Joint Bolt Holes | 0 |
| Number Of Inboard Shaft Bolts | 0 |
| Number Of Inboard Splines | 34 |
| Number Of Outboard Joint Bolt Holes | 0 |
| Number Of Outboard Shaft Bolts | 0 |
| Number Of Outboard Splines | 22 |
| Outboard Bolt Head Size (in) | N/A |
| Outboard Bolt Head Size (mm) | N/A |
| Outboard Bolt Head Type | N/A |
| Outboard Bolt Length (in) | N/A |
| Outboard Bolt Length (mm) | N/A |
| Outboard Joint Bolt Thread Size | N/A |
| Outboard Joint Type | Conventional |
| Outboard Shaft Connection Style | Conventional |
| Overall Compressed Length (in) | 24.25 |
| Overall Compressed Length (mm) | 616 |
| Axle Nut Socket Size | 30 |
| Grade Type | Premium |
| Inboard Joint Boot Material | Neoprene |
| Outboard Joint Boot Material | Neoprene |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708508500 |
| UPC | 00844084030825 |
Part Interchanges
- ARC 80-3339
- EMPI 80-1204
- Car Components Technologies (CCT) 7647
- Mevotech CV9413
- Carquest 410306
- Carquest 800306
- USA Industries 702964
- USA Industries AX-2964
- Prestige Autotech 4325
- American Remanufactured 40-19209
- Drive Tech America GM-9209
- Fenwick CV2964
- CARDONE Reman 60-1031
- CARDONE Reman 66-1031
- OEM Part Number 8944664312
- OEM Part Number 8944664313
- OEM Part Number 94466431
- ODM IZ-8-8509
- TrakMotive GM-8082
- 410306
- NCV33011
- 73579
- 179082
Fits Vehicles
- Geo Storm (1990-1993)
- Isuzu Stylus (1991-1993)
