TrakMotive GM-8034 - CV Axle Shaft
- Part Number
- GM-8034
- Manufacturer
- TRAKMOTIVE
- Description
-
CV Axle Shaft
details
$15249
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
TRAKMOTIVE part description
Product Description
CV Axle Shaft
Product Attributes
| ABS Ring Tooth Count | 55 |
| ABS Ring Type | Toothed |
| Abs Tone Ring Included | Yes |
| Axle Bolt Hex Size (mm) | N/A |
| Axle Bolt Length (mm) | N/A |
| Axle Bolt Thread Size | N/A |
| Axle Nut Head Type | Hex |
| Axle Nut Height (in) | .86 |
| Axle Nut Height (mm) | 22 |
| Axle Nut Hex Size (in) | 1.43 |
| Axle Nut Hex Size (mm) | 36 |
| Axle Nut Included | Yes |
| Axle Nut Length (in) | 1.625 |
| Axle Nut Length (mm) | 42 |
| Axle Nut Locking Type | Self-Lock |
| Axle Nut Thread Size | M24x2 |
| Boot Material | Neoprene |
| Inboard Bolt Head Size (in) | N/A |
| Inboard Bolt Head Size (mm) | N/A |
| Inboard Bolt Head Type | N/A |
| Inboard Bolt Length (in) | N/A |
| Inboard Bolt Length (mm) | N/A |
| Inboard Bolt Thread Size | N/A |
| Inboard Joint Type | Flange |
| Inboard Shaft Connection Style | Flange |
| New Or Remanufactured | New |
| Number of Bolt Holes | 0 |
| Number Of Inboard Joint Bolt Holes | 0 |
| Number Of Inboard Shaft Bolts | 0 |
| Number Of Inboard Splines | 0 |
| Number Of Outboard Joint Bolt Holes | 0 |
| Number Of Outboard Shaft Bolts | 0 |
| Number Of Outboard Splines | 33 |
| Outboard Bolt Head Size (in) | N/A |
| Outboard Bolt Head Size (mm) | N/A |
| Outboard Bolt Head Type | N/A |
| Outboard Bolt Length (in) | N/A |
| Outboard Bolt Length (mm) | N/A |
| Outboard Joint Bolt Thread Size | N/A |
| Outboard Joint Type | Conventional |
| Outboard Shaft Connection Style | Conventional |
| Overall Compressed Length (in) | 21.06 |
| Overall Compressed Length (mm) | 535 |
| Axle Nut Socket Size | 36 |
| Grade Type | Premium |
| Inboard Joint Boot Material | Neoprene |
| Outboard Joint Boot Material | Neoprene |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708508500 |
| UPC | 00844084030344 |
Part Interchanges
- EMPI 80-1511
- Car Components Technologies (CCT) 9419
- Mevotech CV5274
- Carquest 410349
- Carquest 800349
- USA Industries AX-67359
- American Remanufactured 40-16116S
- Drive Tech America GM-6112A
- Fenwick CV2989
- CARDONE Reman 60-1052
- OEM Part Number 26037372
- ODM GC-8-8673A
- TrakMotive GM-8034
- 410349
- NCV10061
- 70805
- 179034
- 92471
Fits Vehicles
- GMC K2500 Suburban (1992-1999)
- GMC K2500 (1992-1999)
- GMC K1500 Suburban (1995-1999)
- Chevrolet K3500 (1992-2000)
- Chevrolet K2500 Suburban (1992-1999)
- Chevrolet K2500 (1992-2000)
- Chevrolet K1500 Suburban (1995-1999)
