CENTRIC 123.63029 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.63029 Specifications
Product Attributes
| Weight [cntrc] Kgs | 5.327 |
| Weight [cntrc] Lbs | 11.720 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Hub Hole / Register [cntrc] Mm | 105.664 |
| Hub Hole / Register [cntrc] In | 4.160 |
| Height [cntrc] Mm | 70.104 |
| Height [cntrc] In | 2.760 |
| Friction Surface Width [cntrc] Mm | 54.610 |
| Friction Surface Width [cntrc] In | 2.150 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 255.500 MM |
| Maximum Brake Diameter (Discard) | 10.060 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 295.910 MM |
| Outside Diameter | 11.650 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 16.000 MM |
| Mounting Hole Diameter | 0.630 IN |
| Nominal Drum Diameter | 254.000 MM |
| Nominal Drum Diameter | 10.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890052616 |
CENTRIC 123.63029 Cross References
| Brand | Part Number |
|---|---|
| 122.63029, F1EZ7D443BB | |
| N/A | 52-102076, 52102076, BD102076, E127-68-034, E128-68-034, 8935, BD8935, 123.63029, 8935G, J5359028, J5359029, 8952002, 8952002952, 5359028, 5359029, 52002952, 140398, PDR0398, 205351, 6401350, 440-1350, 4401350, 861, AD8329, AD8329E, D2349, E12768034, 87252, YH140398, X21631, BD1251, 2349, 2349R, 102349, 2349DGS, 8832029, 78832029, 78-32029, 7832029, 177328, 36542007 |
| PRONTO | BD8935 |
| RAYBESTOS | 2349, 2349R |
| WAGNER | BD102076 |
CENTRIC 123.63029 Fits Vehicles
- Jeep Scrambler (1981-1985)
- Jeep CJ7 (1978-1986)
- Jeep CJ5 (1978-1983)
