(888) 312-8812 Login SignupCENTRIC 123.50003 C-Tek Standard Brake Drum
Tap to view 4 more
$3549
Limited availability at this price!
1 Day Lead Time
Get it by Monday, Jul 27
CENTRIC 123.50003 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.50003 Specifications
Product Attributes
| Weight [cntrc] Kgs | 5.000 |
| Weight [cntrc] Lbs | 11.000 |
| Mounting Type [cntrc] | Hub & Drum |
| Bolt Circle Diameter [cntrc] Mm | 100.000 |
| Bolt Circle Diameter [cntrc] In | 3.937 |
| Stud Thread Pitch [cntrc] Mm | 1.50 |
| Hub Hole / Register [cntrc] Mm | 54.000 |
| Hub Hole / Register [cntrc] In | 2.126 |
| Height [cntrc] Mm | 67.560 |
| Height [cntrc] In | 2.660 |
| Friction Surface Width [cntrc] Mm | 31.220 |
| Friction Surface Width [cntrc] In | 1.229 |
| Product Grade [cntrc] | Standard |
| Stud Thread Size | 12 MM |
| Maximum Brake Diameter (Discard) | 201.000 MM |
| Maximum Brake Diameter (Discard) | 7.913 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 230.000 MM |
| Outside Diameter | 9.055 IN |
| Outer Cooling Fins | No |
| Nominal Drum Diameter | 200.200 MM |
| Nominal Drum Diameter | 7.880 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890094319 |
CENTRIC 123.50003 Cross References
| Brand | Part Number |
|---|---|
| 122.50003, F1EZ15K868G | |
| N/A | 52-126170, 52126170, BD126170, BD126171, 0832845, 35097, 35098, BD35097, BD35098, YH140822, 35097G, 35098G, 0K30A26251A, 0K30C26250A, 140748, PDR0748, PDR0822, 9718, 9719, 87718, 87719, 9718DGS, 9719DGS, 36521003 |
| PRONTO | BD35097 |
| RAYBESTOS | 9719, 9719R |
| WAGNER | BD126170, BD126171 |
CENTRIC 123.50003 Fits Vehicles
- Kia Rio (2001-2002)
