(888) 312-8812 Login SignupCENTRIC 123.46007 C-Tek Standard Brake Drum
Tap to view 4 more
$7249
Limited availability at this price!
1 Day Lead Time
Get it by Friday, Jul 3
CENTRIC 123.46007 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.46007 Specifications
Product Attributes
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 7.273 |
| Weight [cntrc] Lbs | 16.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Hub Hole / Register [cntrc] Mm | 93.500 |
| Hub Hole / Register [cntrc] In | 3.681 |
| Height [cntrc] Mm | 83.000 |
| Height [cntrc] In | 3.268 |
| Friction Surface Width [cntrc] Mm | 57.700 |
| Friction Surface Width [cntrc] In | 2.272 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 256.000 MM |
| Maximum Brake Diameter (Discard) | 10.079 IN |
| Bolt Hole Quantity | 6 |
| Outside Diameter | 303.000 MM |
| Outside Diameter | 11.929 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.300 MM |
| Mounting Hole Diameter | 0.484 IN |
| Nominal Drum Diameter | 254.000 MM |
| Nominal Drum Diameter | 10.000 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890052012 |
CENTRIC 123.46007 Cross References
| Brand | Part Number |
|---|---|
| 122.46007, F1EZ15K857A | |
| MAGMA PRODUCTS | PMU14058 |
| N/A | BD60699, BD61796, 0832053, E127-51-012, E128-51-012, 35033, 3544, BD3544, 123.46007, 63 75 210, MB534245, 116802, 3544G, 35033G, 868, 100757, MB950951, MB534235, MB193596, 140463, 140497, PDR0463, PDR0497, 203720, 6401583, 6401584, DB4173, JBD332, JBD332E, E8383, E12751012, 87319, 87323, 87607, 21094, 9319, 9319R, 9323, 9607, 9323DGS, 9607DGS, 78816007, 8816007, 36572002 |
| PRONTO | BD3544 |
| RAYBESTOS | 9607, 9323 |
| WAGNER | BD61796 |
CENTRIC 123.46007 Fits Vehicles
- Mitsubishi Mighty Max (1983-1996)
- Mitsubishi Montero (1983-1991)
- Dodge Power Ram 50 (1983-1985)
- Dodge Ram 50 (1983-1984, 1986-1993)
- Dodge Raider (1987-1989)
