Centric 120.45101 - Centric Premium Brake Rotor
$4499
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Application Summary
Mazda 3 2022-2019
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Premium rotor; rotors; Centric; brake rotor; break; brake disc; disc brake
Product Attributes
| Discard Thickness | 0.906 IN |
| Nominal Thickness | 25.000 MM |
| Hat Finish | Coated |
| Overall Height | 46.500 MM |
| Outside Diameter | 280.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 67.700 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 13.100 MM |
| California Proposition 65 Text [basic] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating |
| Hat Id [cntrc] In | 5.571 |
| Hat Id [cntrc] Mm | 141.500 |
| Misc Holes [cntrc] | 1 |
| OEM Vane Count [cntrc] | 49 Broken Vanes |
| Vane Style [cntrc] | Broken Vanes |
Additional Information
| NAFTA Preference Criterion Code | B |
| UPC | 00889590535242 |
Fits Vehicles
- Mazda 3 (2019-2023)
