Name: Gates 70593 C5C Hydraulic Hose - SAE 100R5
SKU: 70593
Price: 14.86 USD
Availability: OutOfStock

GATES 70593 Part Description

C5C Hydraulic Hose - SAE 100R5

For use with C5 and C5X Field Attachable Couplings [G34 Series]
Meets or exceeds requirements of SAE 100R5 for traditional hydraulic applications, DOT FMVSS 106-74 TypeAII and SAE J1402 Type AII for air brake applications (-4 to -12)
Meets or exceeds requirements of SAE 100R5 for traditional hydraulic applications, DOT FMVSS 106–74 TypeAII and SAE J1402 Type AII for air brake applications (-4 to -12)
Avoid continuous use at maximum temperature concurrent with maximum working pressures
Temperature Range: Hydraulic Conditions: -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C); All-purpose Fleet Application (Hot Lube Oil Lines) -40 Deg. F to +300 Deg. F (-40 Deg. C to +149 Deg. C)

GATES 70593 Specifications

Product Type	C5C Hydraulic Hose - SAE 100R5
Industrial Description	10C5CXREEL
Type	Fleet Application & Maintenance Hose
Hose Pressure Description	Medium Pressure
Maximum Working Pressure	1750 PS
Burst Pressure	7000 PS
Temperature Rating	-40 Deg. F to +212 Deg. F (Hydraulic); -40 Deg. F to +300 Deg. F (Hot Oil Lines); +160 Deg. F (Air)
Length	275 FT
Dash Size	10
Inside Diameter	.5 IN
Outside Diameter	.92 IN
Bend Radius	5.5 IN
Tube Description	Black, Oil & Heat Resistant Synthetic Rubber
Hose Material	Nitrile - Type C
Reinforcement Material	One Braid of High-Tensile Carbon Steel Wire Over One Braid of Polyester
Cover Material	Polyester Braid
Cover Type	Oil & Mildew Resistant
Cover Color	Black
Coupling Recommendation	C5 Field Attachable
SAE Standard	100R5
EN Standard	N/A
ISO Standard	N/A

Harmonized Tariff Code (Schedule B)	4009410000
Country of Origin (Primary)	MX
UPC	00072053227918
VMRS Code	059032029
UNSPSC	40142000
