ADVICS A6F026U Part Description
Manufacturer
Product Description
ADVICS OE Replacement Disc Brake Rotor
Features & Benefits
- Constructed to OEM weight, vane count and air gap using high carbon metallurgy to maintain thermal stability reducing opportunities for warping while providing longer pad and rotor life. Corrosion protection coating applied to match OEMs.
ADVICS A6F026U Specifications
Product Attributes
| Material | High Carbon |
| Discard Thickness | 0.866 IN |
| Nominal Thickness | 0.984 IN |
| Brake Surface Finish | Non-Directional |
| Overall Height | 1.941 IN |
| Outside Diameter | 10.039 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Center Hole Diameter | 55 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| 9448 | 5 EA |
| Discard Thickness | 22.0 MM |
| Nominal Thickness | 25.0 MM |
| Overall Height | 49.3 MM |
| Outside Diameter | 255.0 MM |
| Mounting Bolt Hole Circle Diameter | 100.0 MM |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| Canadian Harmonizing Tariff Code | 8708309930 |
| UPC | 04562372116193 |
ADVICS A6F026U Cross References
| Brand | Part Number |
|---|---|
| AIMCO | 31541 |
| AISIN | A6F026U |
| Centric Parts | 120.44172 |
| N/A | 50011485, BD180387, 18A2721A, 980750, 31541, JBR1394, 1407-288771, 44662, YH288771, BR900908, 4351247040, BD2047, 900908, A6F026U, 604-76087, YH288771P, 320.44172F, JBR1394EVC |
| Raybestos Brakes | 980750FZN |
| Toyota | 4351247040 |
ADVICS A6F026U Fits Vehicles
- Toyota Prius Plug-In (2012-2015)
- Lexus CT200h (2011-2017)
- Toyota Prius (2010-2015)
