NISSENS part description

Automatic Transmission Oil Cooler

Product Description

Automatic Transmission Oil Cooler

Features & Benefits

  • Special turbulator design
  • Precise brazing process
  • Supreme durability
  • High thermal stress resistance
  • Thermal expansion tested to perform up to 194 degrees Fahrenheit
  • Pressure-impulse tested with 100,000 impulses at a pressure of up to 10.0 bar
  • Manufactured to OE standards in quality, performance and installation fit

Product Attributes

Material Aluminum
Core Height 2.13 IN
Core Length 5.54 IN
Core Width 2.76 in
Outlet Pipe Diameter 0.63 IN
Inlet Pipe Diameter 0.63 IN

Additional Information

Stock Status Q
Warranty Distance 12000
Warranty Distance UOM MI
Country of Origin (Primary) CN
Harmonized Tariff Code (HTS) 8708998180
Canadian Harmonizing Tariff Code 8708999911
UPC 05707286454149

Part Interchanges

Fits Vehicles

  • Mercedes-Benz CLA35 AMG (2020-2023)
  • Mercedes-Benz A35 AMG (2020-2022)
  • Mercedes-Benz A220 (2019-2022)
  • Mercedes-Benz CLA45 AMG (2014-2019)
  • Mercedes-Benz CLA250 (2014-2023)
  • Mercedes-Benz GLA45 AMG (2015-2019)
  • Mercedes-Benz GLA250 (2015-2020)
