(888) 312-8812 Login SignupMOTORAD 1TS1002 Engine Coolant Temperature Sensor
Tap to view 7 more
$1099
Limited availability at this price!
In Stock
Get as soon as Thursday, Oct 8
MOTORAD 1TS1002 Part Description
Manufacturer
Product Description
Engine Coolant Temperature Sensor
Features & Benefits
- 100% factory resistance calibrated to ensure precision tolerances, resulting in extremely accurate temperature for optimal performance
- Thread Sealant and/or O-ring pre-installed on applicable sensors to ensure leak free performance
- Brass sensor housing precision machined to meet or exceed OE thermal conductivity
- OE precision matched thermistor position for correct output parameters
- Extensive product testing includes salt spray, high/low temperature impact, thermal vibration, durability, static electricity, and micro tension, among other tests, to ensure all sensors meet or exceed OEM specifications.
MOTORAD 1TS1002 Specifications
Product Attributes
| Terminal Type | Blade |
| Connector Shape | Cuadrado |
| Terminal Quantity | 2 |
| Connector Gender | Female |
| Wiring Harness Included | No |
| Mounting Hole Quantity | 0 |
| Terminal Gender | Male |
| Thread Type | Fine |
| Thread Sealer Included | No |
| Threaded End Diameter | 0.29 IN |
| Thread Size | 1/4" - 20 IN |
| Mounting Type | Threaded |
| Connector Length | 0.75 IN |
| Mounting Bracket Included | No |
| Height | 60.45 mm |
| Overall Width | 19.04 mm |
| Material | Metal, Plástico |
| Sensor Casing Length | 0.75 IN |
| 10797 | 0.63 IN |
| 10812 | 0.75 IN |
| Resistance | 2.014 82 |
| Color | Negro, Oro |
| Wire Quantity | 0 |
| Grade Type | Standard Replacement |
| Connector Quantity | 1 |
| Gasket Or Seal Included | No |
| Sensor Casing Length | 19.05 MM |
| 10797 | 16.00 MM |
| 10812 | 19.05 MM |
| Threaded End Diameter | 7.44 MM |
| Connector Length | 19.05 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8481809015 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8481809015 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00055644923673 |
MOTORAD 1TS1002 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 2131099, 2133733, 213389, 213395, 213396, 213397, 2133987, 213400, 213418, D583 |
| AISIN | THSAZ-8001 |
| Ford | F32Z12A648A, F42Z10884A, F42Z10884AA, F4BZ12A648A, F62Z12A648AA |
| General Motors | 19022018, 19138984, 19146026, 19160446, 88924811, 88975489, 88975490, 91171786, 94847363, 94853124, 96062513, 96065716, 96068627 |
| Jaguar | LNA1600AA |
| Kia | MB59318840A |
| Mazda | B3C818840, B59318840, B59318840A, FS1518840, NF0218840 |
| Motorad | 1TS1002 |
| Motorcraft | SWE2374, SWE2509 |
| N/A | 1580421, TS5723, 9334, 140715, EF0105, WT5123, TS10051, 8942206010, 31212, TS6677SB, SU13825, 5S1516, 1797000110, TX40, 712565, 2CTS0016, 140748, 140751, TW183, 894220H010, WTC1005, 712567, 712597, 712682, 9381, 9390, 5S1517, 5S1616, WT653, 1580783, WT653P, TS10198, TS10173, 1931000, 1797000220, SU6775, SU4007, SU4320, TS6677, 2CTS0051, 2CTS0113, 2CTS0387, 2CTS0474, EF0119, EF0157 |
| Pep Boys | 1TS1002 |
| STANDARD IGNITION | TX40 |
| Stant | 74138, 74211, 74027 |
| Subaru | 22630KA020 |
| Suzuki | 1365051G10, 1365057F00, 1365061B00 |
| Toyota | 8942220010, 8942230030, 8942233020, 8942235010 |
| Volvo | 8653103, 86531030 |
| WALKER PRODUCTS | 2111060, 211-1060 |
MOTORAD 1TS1002 Fits Vehicles
- Volvo C70 (2002-2004)
- Volvo S60 (2002-2009)
- Volvo S80 (2004-2006)
- Volvo V70 (2002-2007)
- Volvo XC70 (2003-2007)
- Volvo XC90 (2003-2006)
- Chevrolet Sprint (1990-1991)
- Chevrolet Tracker (1991, 1998)
- Ford Aspire (1994-1996)
- Ford Probe (1993-1994, 1996-1997)
- Ford Thunderbird (2002-2005)
- GMC Tracker (1991)
- Geo Metro (1992-1996)
- Geo Prizm (1989-1997)
- Geo Tracker (1991-1997)
- Jaguar Super V8 (2005)
- Jaguar Vanden Plas (1998-2005)
- Jaguar X-Type (2002-2008)
- Jaguar XJ12 (1995-1996)
- Jaguar XJ8 (1998-2005)
- Jaguar XJR (1998-2005)
- Jaguar XK8 (1997-1999, 2003-2006)
- Jaguar XKR (2003-2006)
- Kia Sephia (1995-1997, 1999)
- Lexus CT200h (2011-2017)
- Lexus ES250 (1990-1991)
- Lexus ES300 (1992-2003)
- Lexus ES300h (2013-2018)
- Lexus ES330 (2004-2006)
- Lexus ES350 (2007-2018)
- Lexus GS F (2016-2020)
- Lexus GS200t (2016-2017)
- Lexus GS300 (1993-2006, 2018-2019)
- Lexus GS350 (2007-2011, 2013-2015)
- Lexus GS400 (1998-2000)
- Lexus GS430 (2001-2007)
- Lexus GS450h (2007-2011, 2013-2018)
- Lexus GS460 (2008-2011)
- Lexus GX460 (2010-2023)
- Lexus GX470 (2003-2009)
- Lexus HS250h (2010-2012)
- Lexus IS F (2008-2014)
- Lexus IS200t (2016-2017)
- Lexus IS250 (2006-2015)
- Lexus IS300 (2001-2005, 2016-2025)
- Lexus IS350 (2006-2017)
- Lexus IS500 (2022-2025)
- Lexus LC500 (2018-2025)
- Lexus LFA (2012)
- Lexus LS400 (1990-2000)
- Lexus LS430 (2001-2006)
- Lexus LS460 (2007-2017)
- Lexus LS500 (2018-2025)
- Lexus LS600h (2008-2016)
- Lexus LX450 (1996-1997)
- Lexus LX470 (1998-2007)
- Lexus LX570 (2008-2011, 2013-2021)
- Lexus NX200t (2015-2017)
- Lexus NX300 (2018-2021)
- Lexus NX300h (2015-2021)
- Lexus NX350 (2022-2025)
- Lexus RC F (2015-2025)
- Lexus RC200t (2016-2017)
- Lexus RC300 (2016-2025)
- Lexus RC350 (2015-2018)
- Lexus RX300 (1999-2003)
- Lexus RX330 (2004-2006)
- Lexus RX350 (2007-2015, 2023-2025)
- Lexus RX400h (2006-2008)
- Lexus RX450h (2010-2015)
- Lexus RX500h (2023-2025)
- Lexus SC300 (1992-2000)
- Lexus SC400 (1992-2000)
- Lexus SC430 (2002-2010)
- Lexus TX350 (2024-2025)
- Lexus TX500h (2024-2025)
- Lincoln LS (2003-2006)
- Mazda 2 (2011-2014)
- Mazda 3 (2010-2018)
- Mazda 3 Sport (2012-2015)
- Mazda 6 (2014-2017)
- Mazda 626 (1993-2002)
- Mazda 929 (1992-1995)
- Mazda B2200 (1992-1993)
- Mazda CX-5 (2013-2016)
- Mazda MPV (1992-1998)
- Mazda MX-3 (1992-1996)
- Mazda MX-6 (1993-1997)
- Mazda Miata (1994-1997)
- Mazda Millenia (1995-2002)
- Mazda Protege (1995-1996, 2000-2003)
- Mazda Protege5 (2002-2003)
- Mazda RX-7 (1993-1995)
- Mazda RX-8 (2004-2011)
- Pontiac Firefly (1987-1991, 1994-1996)
- Pontiac Sunrunner (1995-1997)
- Pontiac Vibe (2003-2010)
- Scion iM (2016)
- Scion iQ (2012-2015)
- Scion tC (2005-2016)
- Scion xA (2004-2006)
- Scion xB (2004-2006, 2008-2015)
- Scion xD (2008-2014)
- Subaru Justy (1990-1994)
- Suzuki Samurai (1985-1995)
- Suzuki Sidekick (1991-1998)
- Suzuki Swift (1992-1995)
- Suzuki X-90 (1996-1998)
- Toyota 4Runner (1989-2025)
- Toyota Avalon (1995-2018)
- Toyota Avanza (2022)
- Toyota C-HR (2018-2022)
- Toyota Camry (1989-2017)
- Toyota Celica (1989-2005)
- Toyota Corolla (1987-1997, 2003-2025)
- Toyota Corolla iM (2017-2018)
- Toyota Cressida (1989-1992)
- Toyota Crown (2023-2025)
- Toyota Echo (2000-2005)
- Toyota FJ Cruiser (2007-2014)
- Toyota Grand Highlander (2024-2025)
- Toyota Hiace (2006-2016)
- Toyota Highlander (2001-2019, 2023-2025)
- Toyota Hilux (2006, 2016-2023)
- Toyota Land Cruiser (1989-2011, 2013-2021, 2024-2025)
- Toyota MR2 (1991-1995)
- Toyota MR2 Spyder (2000-2005)
- Toyota Matrix (2003-2014)
- Toyota Mirai (2016-2020)
- Toyota Paseo (1992-1998)
- Toyota Pickup (1989-1995)
- Toyota Previa (1991-1997)
- Toyota Prius (2001-2022)
- Toyota Prius AWD-e (2019-2022)
- Toyota Prius C (2012-2019)
- Toyota Prius Plug-In (2012-2015)
- Toyota Prius Prime (2017-2022)
- Toyota Prius V (2012-2018)
- Toyota RAV4 (1996-2018)
- Toyota Sequoia (2001-2022)
- Toyota Sienna (1998-2016)
- Toyota Solara (1999-2008)
- Toyota Supra (1989-1998)
- Toyota T100 (1993-1998)
- Toyota Tacoma (1995-2025)
- Toyota Tercel (1989-1998)
- Toyota Tundra (2000-2021)
- Toyota Van (1984-1989)
- Toyota Van Wagon (1988)
- Toyota Venza (2009-2016)
- Toyota Yaris (2006-2018, 2021-2023)
