WABCO 412704008R - Air Brake Compressor - Twin Cylinder, Flange Mounted, Water Cooling
$5,20799
+$562.50 Core Deposit
Total price w/ core: $5,770.49
14 day lead time
. Learn more
WABCO part description
Product Attributes
| Max. operating pressure | 181.3 psi |
| Max. operating pressure | 181.3 psi |
| Port Thread 0 | Ø 34.9 mm |
| Piston Diameter | 3.35 in |
| Calculated Volume (dm³) | 22.9856 |
| Swept Volume (Cm³) | 704 cm3 |
| Operating speed | 3000 (1/min) |
| Port Thread 9.2 | M16 x 1.5 |
| Size | 331 x 171 x 290 |
| Weight | 41.51 |
| Piston stroke | 62 mm |
| Crankshaft thread | M20 x 1.5 |
| Type | Twin Cylinder |
| Cooling | Water |
| Mounting | Mounting Flange |
| Port thread 4 | M12 x 1.5 |
| Port Thread 8.1 | M12 x 1.5 |
| Lubrication | Lubrication supplied from engine |
| Port thread 2 | M26 x 1.5 |
| Port Thread 9.1 | M16 x 1.5 |
WABCO 412704008R Cross Reference
We have 1 alternatives for the 412704008R by WABCO:
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
