GATES 9520 Automotive XL High Capacity V-Belt

★★★★★ (0) Write a Review
9520 by GATES - Automotive XL High Capacity V-Belt
GATES
Tap to view 1 more

MSRP: $32.62

$26.49

Save $6.13

Limited availability at this price!

In Stock

Get it by Friday, Jan 2
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed before 2pm EST will ship same day

GATES 9520 Part Description

Manufacturer

GATES

Product Description

Automotive XL High Capacity V-Belt

Application Summary

1986-1980 Ford, F Series Pickup, V-8 5.0 L, Fan & P.S.

Features & Benefits

  • Fiber-loaded rubber stock adds flexibility along the length of the belt and provides greater lateral stability in the pulley
  • Form-ground to ensure precise top width and sidewall dimensional control for proper fit to the pulley
  • Thermally-active tensile cords for maintenance-free performance when properly installed and tensioned
  • Resists oil, heat, ozone, weather and aging for improved belt life
  • Meets or exceeds SAE J636C specifications

GATES 9520 Specifications

Product Attributes

Type High Capacity V-Belt (Standard)
Cross Section Designation HC50
Angle 36
Strand Quantity 1
Top Width .47 in
Outside Circumference 52.61 in
Effective Length 52 in
Construction Notched
Notched Yes
Belt Material EPDM
Cord Material Polyester
Top Width 12 mm
Outside Circumference 1336 mm
Effective Length 1321 mm

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (Schedule B) 4010323000
UPC 00072053312355
VMRS Code 065005003
UNSPSC 26111801

GATES 9520 Part Interchanges

Brand Part Number
Beck/Arnley 141-0224, 145-041325
Bosch 1987947621, 910416-2265, 910416-2268, 911416-2265, 916416-2265
Canadian Tire 13A1320, 14-0824-8
Carquest Red 17520
Charter 17520
Mopar B-17521-A, B0017521, BH-1711, JY017521, B0015521
Motorcraft EJV-525, JC-524
Mighty 17520
Bravo 17520
Sierra 18-17520
Uniroyal 17520
White 027015400, 027023764, 027069450, 027069454, 031105095, 049031011, 11A21178, 176894A, 203005083, 204051A, 303384292, 311676450, 79288A, 79582, 8002598, 205987A, 208213, 79700A
ACDelco 9520HD, 17521
Dayco 13V1320, 17516, 17520, 17520DR, 17521, 17523, 420338, 421643, 421739, 422303, 422332, 422855, 422909, 423191, 423192, 423618, 423766, 423824, 423842, 424221, 425898, 426114, 426920, 426921, 427419, 427421, 427422, 430295, 432842, 432846, 433141, 434550, 434725, 434899, 435013, 435076, 435082, 43946, 44387, 44752, 44783, 450, 48342, 48361, 50249, 52017, 52684, 53142, 53777, 54187, 54413, 54436, 54514, 54881, 55009, 55053, 55138, 55150, 55162, 55184, 55651, 55685, 55747, 57065, 57425, 57707, 58076, 58918, 59164, 59220, 59828, 642, 696, 697, V450
BF Goodrich 16523
Firestone 51308484
Ingersoll/Rand 35308634, 59075788, GPG299
Leece-Neville 57812, 57846
Carquest 9520HD, 9520
Shell 45
Acme Machine 4500759
Advance Machinery 480828A
AGCO 3777681M91, 844079M1, V684121325
Allis Chalmers 1193748, 254075, 3009X19, 3059X5, AX89514
American Lafrance 257900021A18
Armormark 17520
Atlas (Canada) A16523
Bando 3510, 4520, B3510, RPF3520
Bendix-Westinghouse 238100, 241037
British Leyland AMK864
Carrier Transicold A3100525
Case Tractor 79802, A22608, D131146, L45532, L45826, S0038725, A33544
Caterpillar 2552960, 2P6147, 30628, 4N6130, 4N8597, 5L7553, 5S1204, 9L0894, 9L0895, 9L1554, 9L894, 9L895
Charles Machine 170049
Chrysler 1554726, 1614688, 2202767, L50520A50
Clark Equipment 5207185, 660056, 713551, 95C3722, PGF18264, PGF18264A
Climax Engr 41279
Columbus 17520
Conoco 17520, AB190
Continental Belt 6578770, 6587491, AV13-1325, V2213, V626
Cummins 176283, 197171, 3004311, 3040311, 3040312
Datsun/Nissan 11920R9040, 21066T9303
Deutz 1168328
Deutz-allis 70254075, 71193749, 74023405
Divco Trucks 528073
Dunlop 3520, V581
Epton 16523
First Products 17-520
Fleetrite ZAH17520, ZJG17521
Food Machine 1055526
Frigiking 0401523, 04015231, 116250, 9102695, 9117037, A50HC
Gardner Denver 13AE12
Gehl 02032158
General Motors 0258519, 11502373, 11502374, 15503213, 2031262, 2345610, 2483912, 2486894, 3888487, 3906417, 5126253, 5131837, 5136272, 513837, 5173884, 796306, 9433909
ContiTech 13X1325, AV5520
MasterPro 17520, 9520
Ford C2TE 8620 A, C4TE 8620 D, C4TE 8620 Y, C4TZ 8620 D, C6TZ 8620 K, C7AA 8620 A, C7AZ 8620 A, C7OE 8620 D, C8HA 8620 E, C8HZ 8620 A, C9PZ 8620 CM, C9PZ 8620 U, D0AE 8620 B, D0AZ 8620 B, D0HA 8620 C, D0HA 8620 Z, D0HA 8A615 H, D0OE 8620 A, D0OE 8620 K, D0OZ 8620 B, D0VE 8620 D, D0VZ 8620 B, D2AE 8620 BSA, D2AE 8620 BSE, D2OE 8620 AYA, D2TE 8620 AT, D2TE 8620 ATA, D2TE 8620 PSA, D2VE 8620 LA, D5HE 8620 HA, D9PZ 8620 U, E0TA 8A615 BA, E0TE 8A615 BA, EBJ 8620 B
Toyota 9933211306, 9933251300, 9952211306
Honda 0001801523
Isuzu 5136711240
Mitsubishi MB182216
Mercedes-Benz 0009978892, 0019971592, 0019972392, 0019981592, 0039976292, 007753012514, 007753012515, 0099977892
Volkswagen 023260849
Volvo Cars 950858, 952260, 958503, 958548, 966390, 966398, 967261, 978773, 978774, 978775, 978776, 978777, 978778
International Harvester (IHC) 166576H1, 254329C1, 291019C1, 291019C11, 291019C21, 291019C22, 311176C2, 3144678R1, 355707C91, 358321C91, 382228R1, 382228R2, 473762C91, 473763C91, 676835R1, 680611K11, 680611R1, 680611R11, 680611R2, 680611R21, 830639, 998237R1
Iveco 4855027, 98420270
John Deere 69X34760A, QX721182, W16896A
Massey Ferguson 1336301, 1876670M1, 268847M91, 268849M91, 513833M1, 535471DA, 723558M1, 726322M1, 726323M91, 761141M1, 767141M1, VX111470
Hyster 128898, 211218, 79853, 127157
Oshkosh 9CA833
Reo Trucks 1124A7
Towmotor C629028C30
Western Auto 77-9806-9
Mobil 17-520, 413L
Hesston 856518
Kamada 17W520L
Kioti E7240-72531
Kysor 300107, B1140452
Lincoln Electric S11872
MAN 81968206010
Manitowoc 227292
Mitsuboshi MF2520, MF6510, RECMF2520, RECMF6510, REMF2520, REMF6510, MF6505, RECMF6505, REMF6505
Montgomery Ward 359610, 610
New Holland 592712
Onan 511016802, 511095, 51195, 511P95
Optibelt 2265
Pacific Car & Foundry 2800043520, 2800054515
Petro-Canada 13G1320
Roadmax 17520AP
Sears 23085, 51610, 610, 67623
Steiger Tractor 061451A
Sunoco 17520, 413
Texaco 17520, 554
Thermo-King 18VRW25, 2028B89H03, 2028B89H17, 789003
Timberjack 810462800
Toro 70-3450
Trugrip 17520
Ultralast 17520
Unocal 76 17520, 379
Vera 55-13256
Vermeer 865850011
Flennor AVX13X1325LA
Waukesha 157176, A157176, C157176
Worldparts W51-129
Mack 88GB29301P24, 88GB354P69, 88GB354P72, 88GB437P5, 88GB439P521
Freightliner Trucks 2310001063, GT17522, GT17527
Blue Bird 2022952, 2619971, 3302022952
Goodyear 1251325, 1302H, 13AV1325, 17515MK, 17520, 17520MK, 17521
GRADALL 91033248
Volvo GM Heavy Truck V1090828, V1090984
Parts Master 17520
NAPA Belts/Hose 25-9520HD, 25-9520
Cadna Belts and Hose 17520
Atlas 7520, 813
Alliance Truck Parts GT17515, GT17522E, GT17522, GTFLN9520
ARA Manufacturing 0110050, 0111100, 0116700, 1111, 1136, 1167
Autopar FB17520, FB17525, FB233
Durkee-Atwood 17-523
Eaton, Yale & Towne 2038681, 2039583, 211881, 212222, 213990, 24465, A211218
Gulf G212L
John E. Mitchell 11400, 12127, JEM50, UA50S, VA50S
Lift Parts 1568260, 1568267
MBL Three Stars 17520
NAPA 17520, 25-13205, 401-9520
PIX A-268847M91, A-71193749
Pro-1 P9520
Seaman 298704291
Service King 259, 266
Teledyne Continental M330V203, M363V202
Temp Con 0200089
U.S. Government 3030009822780, MS51066P52, ZZB1902P52B
Van Dorn 211749
Volvo White 208045006, 208045034, 208045059
Vornado 31A50SCH
Yale 21222, 502028903
Perkins 0070086, 0070110, 2612428, 2614B054, 2614B153, 2614B154
HD Value 17520HDV
<Unknown> 0023255703, 0023255704, 0034520200, 0036796200, 00775, 030628, 06580430234, 06580472234, 06580722342, 165031, 178778, 1800867, 1A60664, 200006627, 23223100, 2612375, 2832249, 289842, 322225, 323225, 323665, 3981921, 4716471, 4767724002, 4767724003, 488082, 4950, 5000021655, 5000042052, 5035282, 50520A50, 55017, 583833M1, 61200060084, 660101, 684121300, 684121325, 7013300029, 720500217, 720500450, 723588M1, 761474, 79582A, 814199, 826, 8819672, 90003140037, 90003142574, 90401523, 921151325, 95C3723, 960475, A0039973292, A127157, A30628, A41839, A50, C7OE 8620 Y, D72194, E38393, IEX16106, NKJ3718, SK38165, SK71159, SK71164
Metric 12.5X1325LA, 13A1320, 13A1325
Size Designation 17527

GATES 9520 Fits Vehicles

  • Volvo 142 (1972)
  • Volvo 145 (1972)
  • Volvo 144 (1972)
  • Freightliner FLD120 (1996)
  • Mack CL (1992-1994)
  • Mack RW (1990-1993)
  • Mack MH (1990-1993)
  • Peterbilt 377 (1992-1994)
  • Peterbilt 362 (1983-1991)
  • Kenworth C500 (1989-1994)
  • Peterbilt 359 (1984-1987)
  • Peterbilt 385 (1996-1998)
  • Peterbilt 375 (1987-1993)
  • Peterbilt 320 (1991-1992)
  • Peterbilt 357 (1987-1998)
  • Peterbilt 379 (1987-1998)
  • Peterbilt 378 (1988-1998)
  • Kenworth W900 (1994-1999, 2004)
  • International 2155 (1979-1980)
  • Kenworth T800 (1987-1997, 1999)
  • Kenworth T600A (1987-1999)
  • Kenworth T2000 (1998-1999)
  • International 1854 (1979-1981)
  • International F1954 (1979-1982)
  • International 1955 (1979-1982)
  • International 1954 (1979-1980)
  • International 1654 (1980-1982)
  • International 1754 (1979-1982)
  • International 2275 (1979-1980)
  • International S1854 (1981)
  • International 9400 (1991)
  • International 8300 (1990-1993)
  • International 8200 (1990-1993)
  • International 8100 (1990-1994)
  • International 9300 (1988, 1991)
  • International S1853 (1981-1982)
  • International S1754 (1981-1982)
  • Volvo 1800 (1972-1973)
  • Ford LN8000 (1981-1983)
  • Mercury Villager (1967)
  • Mercury Voyager (1967)
  • Mercury Marauder (1970)
  • Mercedes-Benz 280SE (1970-1972)
  • Jaguar XKE (1967-1969)
  • GMC PB15 Series (1966)
  • Ford C900 (1981)
  • GMC C5000 (1979)
  • Ford F-200 (1986)
  • White/GMC WX (1988)
  • Ford Custom (1967-1968, 1970-1972)
  • Ford LN700 (1980-1985)
  • Ford LN600 (1980-1985)
  • Ford C800 (1980-1986)
  • Ford C700 (1980-1986)
  • Ford C600 (1980-1986)
  • Toyota Stout (1967-1968)
  • Plymouth Sapporo (1980)
  • Plymouth Colt (1980)
  • Toyota Pickup (1969)
  • GMC C6000 (1979)
  • GMC Brigadier (1981-1985)
  • Chevrolet C60 (1977-1979)
  • Chevrolet C50 (1973-1979)
  • Mercury Monterey (1970-1974)
  • Mercury Cyclone (1967-1968, 1970-1971)
  • Mercury Comet (1967-1968)
  • Mercury Colony Park (1970-1974)
  • Mercury Caliente (1967)
  • Mercedes-Benz 280SEL (1970-1971)
  • Mercedes-Benz 280S (1970-1971)
  • Mercedes-Benz 250C (1970-1972)
  • Lincoln Mark III (1970-1971)
  • Lincoln Continental (1970-1971)
  • GMC Suburban (1966)
  • GMC PB25 Series (1966)
  • GMC P35/P3500 Van (1967-1974)
  • GMC P25/P2500 Van (1967-1974)
  • GMC P15/P1500 Van (1967)
  • GMC K35/K3500 Pickup (1968-1974)
  • GMC K25/K2500 Suburban (1967-1974)
  • GMC K25/K2500 Pickup (1967-1974)
  • GMC K15/K1500 Pickup (1967-1974)
  • GMC C35/C3500 Pickup (1967-1974)
  • GMC C25/C2500 Suburban (1967-1974)
  • GMC C25/C2500 Pickup (1967-1974)
  • GMC C15/C1500 Suburban (1967-1974)
  • GMC C15/C1500 Pickup (1967-1974)
  • Ford Ranch Wagon (1967-1968, 1970-1974)
  • Ford LTS8000 (1981-1983)
  • Ford L8000 (1981-1983)
  • Ford LT8000 (1981-1983)
  • Mercedes-Benz L1319 (1987-1989)
  • Ford LNT8000 (1981-1983)
  • White WX (1982-1988)
  • Ford Elite (1975-1976)
  • Mercedes-Benz 250 (1970-1972)
  • Toyota Hi-Lux (1969)
  • GMC K15/K1500 Suburban (1967-1968, 1970-1971)
  • Ford Galaxie (1967)
  • Ford Galaxie 500 (1967-1968, 1970-1974)
  • Ford Falcon (1967-1968, 1970)
  • Ford Fairlane (1967-1968, 1970)
  • Ford Country Squire (1967-1968, 1970-1974)
  • Ford Country Sedan (1967-1968, 1970-1974)
  • Chevrolet P20 Series (1963-1967)
  • Chevrolet Suburban (1963-1966)
  • Chevrolet P30 Van (1968-1974)
  • Chevrolet P30 Series (1963-1967)
  • Chevrolet P20 Van (1968-1974)
  • Chevrolet P10 Series (1967)
  • Chevrolet K30 Pickup (1968-1974)
  • Chevrolet K10 Suburban (1967, 1969-1970)
  • Chevrolet K20 Suburban (1967-1974)
  • Chevrolet K20 Pickup (1963-1974)
  • Chevrolet K10 Pickup (1963-1974)
  • Chevrolet C30 Pickup (1963-1974)
  • Chevrolet C20 Suburban (1967-1974)
  • Chevrolet C20 Pickup (1963-1974)
  • Chevrolet C10 Suburban (1967-1974)
  • Chevrolet C10 Pickup (1963-1974)
  • Toyota Corona (1977-1978)
  • Toyota Celica (1977-1978)
  • Honda Accord (1981)
  • Mitsubishi Mighty Max (1983-1986)
  • Honda Civic (1975-1979)
  • Ford Pinto (1977-1979)
  • Mercury Montego (1968, 1970-1976)
  • Mercury Zephyr (1980-1982)
  • Ford Fairmont (1980-1982)
  • Mercury Monarch (1975-1980)
  • Mercury Marquis (1970-1978)
  • Mercury Grand Marquis (1975-1978)
  • Mercury Bobcat (1977-1979)
  • Mercury Cougar (1967-1968, 1970-1976, 1978-1979)
  • Mercury Capri (1967, 1972-1974, 1979, 1983)
  • Ford Torino (1968, 1970-1976)
  • Ford Thunderbird (1970-1971, 1973, 1977-1979)
  • Ford Mustang (1967-1968, 1970-1973, 1979, 1983)
  • Ford LTD II (1978-1979)
  • Ford Ranchero (1967-1968, 1970-1976, 1978-1979)
  • Ford Mustang II (1977)
  • Ford Granada (1975-1980)
  • Ford Gran Torino (1972-1976)
  • Ford F-500 (1975-1977)
  • Ford F-350 (1973-1986)
  • Ford F-250 (1973-1986)
  • Ford F-150 (1975-1986)
  • Ford F-100 (1973-1974, 1978-1983)
  • Ford E-350 Econoline Club Wagon (1980-1982)
  • Ford E-350 Econoline (1980-1982)
  • Ford E-250 Econoline Club Wagon (1980-1982)
  • Ford E-250 Econoline (1980-1982)
  • Pontiac Grand Am (1990-1991)
  • Ford E-150 Econoline Club Wagon (1980-1982)
  • Ford E-150 Econoline (1980-1982)
  • Ford E-100 Econoline Club Wagon (1980-1982)
  • Ford Custom 500 (1967-1968, 1970-1976)
  • Ford E-100 Econoline (1980-1982)
  • Ford LTD (1967-1968, 1970-1978)
  • Ford Bronco (1978-1981, 1985-1986)
  • Oldsmobile Cutlass Calais (1990-1991)
  • Buick Skylark (1990-1991)
  • Plymouth Champ (1979-1980)
  • Plymouth Arrow (1980)
  • Plymouth Arrow Pickup (1979-1980)
  • Dodge D50 (1979-1980)
  • Dodge Colt (1979-1980)
  • Dodge Challenger (1980)

GATES 9520 Cross References

We have 3 alternatives for the 9520 by GATES:

GATES 9520 Customer Reviews

No reviews yet

Be the first to review this product!

Write a Review
California Proposition 65 Warning California residents see

Recommended Products

More from GATES

(Browse all)
