NTK MA0089 Part Description
Manufacturer
Product Description
NTK Manifold Absolute Pressure Sensor
Features & Benefits
- The Manifold Absolute Pressure Sensor (MAP) provides manifold pressure information to the Engine Control Unit (ECU). The data is used to determine the air mass flow rate and required fuel for optimum combustion and ignition timing.
- NTK's Manifold Absolute Pressure Sensors are manufactured to operational performance standards to meet or exceed OE fit, form and function to ensure proper manifold pressure, fuel metering and ignition timing.
- Backed by a 3 year/36,000-mile warranty.
NTK MA0089 Specifications
Product Attributes
| Terminal Type | Pin |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Terminal Quantity | 3 |
| Connector Gender | Female |
| Terminal Gender | Female |
| Port Quantity | 1 |
| Grade Type | Standard Replacement |
| Connector Color | Black |
| Mount Type | Bolt On |
| Wiring Harness Included | No |
| Housing Color | Black |
| Body Material | Plastic |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 36000 |
| Harmonized Tariff Code (Schedule B) | 9026200000 |
| Harmonized Tariff Code (HTS) | 9026200000 |
| Warranty Time UOM | MO |
| Warranty Time | 36 |
| Country of Origin (Primary) | US |
| UPC | 00087295743393 |
NTK MA0089 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 213-1545, 213-187, 213-185, 213-356 |
| American Motors | 8933000153 |
| BWD | EC1602P, EC1633P, EC1602, EC1633, EC1651 |
| Beck/Arnley | 158-0380 |
| Chrysler | 33000153, 33000273, 33004212, 4723039 |
| Delphi | PS10075, PS10077 |
| Echlin | 2-16450, 2-19325, 2-19060, 2-1961 |
| General Motors | 12569240, 16017460, 16137039, 16158055, 16254719, 21020103, 17112715 |
| HOLSTEIN | 2MAP0005 |
| Isuzu | 8-12569-240-0, 8-16017-460-0, 8-16137-039-0, 8-16158-055-0 |
| Saturn | 21020103 |
| Standard Motor Products | AS17, AS5 |
| URO | GM1317807 |
| Volvo | 3517892-0 |
| Walker Products | 225-1001 |
NTK MA0089 Fits Vehicles
- Volvo 740 (1989-1992)
- Volvo 940 (1991-1995)
- AM General Hummer (1995-1996)
- Acura SLX (1996-1997)
- Asuna GT (1993)
- Asuna SE (1993)
- Buick Century (1982-2004)
- Buick Commercial Chassis (1991-1996)
- Buick Electra (1985, 1988-1989)
- Buick LeSabre (1988-1990)
- Buick Regal (1984-1985, 1988-1996)
- Buick Rendezvous (2002-2003)
- Buick Riviera (1984-1985)
- Buick Roadmaster (1991-1996)
- Buick Skyhawk (1982-1989)
- Buick Skylark (1982-1998)
- Buick Somerset (1986-1987)
- Buick Somerset Regal (1985)
- Cadillac Brougham (1987-1992)
- Cadillac Cimarron (1983-1988)
- Cadillac Commercial Chassis (1994-1996)
- Cadillac DeVille (1985)
- Cadillac Eldorado (1985)
- Cadillac Fleetwood (1985-1986, 1993-1996)
- Cadillac Seville (1985)
- Chevrolet Astro (1985-1991)
- Chevrolet B60 (1990-1991)
- Chevrolet B7 (1993-1998)
- Chevrolet Beretta (1987-1996)
- Chevrolet Blazer (1987-1994)
- Chevrolet C10 (1984)
- Chevrolet C1500 (1988-1997)
- Chevrolet C1500 Suburban (1992-1995)
- Chevrolet C20 (1984)
- Chevrolet C2500 (1988-1998)
- Chevrolet C2500 Suburban (1992-1995)
- Chevrolet C3500 (1988-1995)
- Chevrolet C3500HD (1991-1995)
- Chevrolet C5500 Kodiak (1990-1991)
- Chevrolet C60 (1989-1990)
- Chevrolet C60 Kodiak (1990-1996)
- Chevrolet C6500 Kodiak (1997-1998)
- Chevrolet C70 (1989-1990)
- Chevrolet C70 Kodiak (1990-1996)
- Chevrolet C7500 Kodiak (1997-1998)
- Chevrolet Camaro (1982-1986, 1988-1997)
- Chevrolet Caprice (1982-1983, 1985-1996)
- Chevrolet Cavalier (1983-1997)
- Chevrolet Celebrity (1982-1990)
- Chevrolet Chevy (1994-2008)
- Chevrolet Chevy Monza (2003)
- Chevrolet Chevy Pickup (1999-2003)
- Chevrolet Citation (1982-1983)
- Chevrolet Citation II (1984-1985)
- Chevrolet Commercial Chassis (1991-1994)
- Chevrolet Corsa (2002)
- Chevrolet Corsica (1987-1996)
- Chevrolet Corvette (1982, 1984, 1990-1996)
- Chevrolet El Camino (1985-1987)
- Chevrolet Express 2500 (1996)
- Chevrolet G10 (1987-1995)
- Chevrolet G20 (1984-1985, 1987-1995)
- Chevrolet G30 (1987-1996)
- Chevrolet Impala (1994-1996, 2000-2004)
- Chevrolet K10 (1984)
- Chevrolet K10 Suburban (1984)
- Chevrolet K1500 (1988-1996, 1998)
- Chevrolet K1500 Suburban (1992-1995)
- Chevrolet K20 (1984)
- Chevrolet K2500 (1988-1995)
- Chevrolet K2500 Suburban (1992-1995)
- Chevrolet K3500 (1988-1995)
- Chevrolet K5 Blazer (1984)
- Chevrolet LLV (1987-1995)
- Chevrolet Lumina (1990-2001)
- Chevrolet Lumina APV (1990-1996)
- Chevrolet Malibu (1982-1983, 1997-2003)
- Chevrolet Monte Carlo (1982-1988, 1995-2004)
- Chevrolet P20 (1987-1989)
- Chevrolet P30 (1987-1999)
- Chevrolet P6000 (1992-1996)
- Chevrolet R10 (1987)
- Chevrolet R10 Suburban (1987-1988)
- Chevrolet R1500 Suburban (1989-1991)
- Chevrolet R20 (1987-1988)
- Chevrolet R20 Suburban (1987-1988)
- Chevrolet R2500 (1989)
- Chevrolet R2500 Suburban (1989-1991)
- Chevrolet R30 (1987-1988)
- Chevrolet R3500 (1989-1991)
- Chevrolet S10 (1985-1997)
- Chevrolet S10 Blazer (1985-1994)
- Chevrolet Silverado (1995)
- Chevrolet Suburban (1991)
- Chevrolet T6500 (1997-1998)
- Chevrolet T7500 (1997-1998)
- Chevrolet Tahoe (1995-1999)
- Chevrolet Tigra (1999)
- Chevrolet V10 (1987)
- Chevrolet V10 Suburban (1987-1988)
- Chevrolet V1500 Suburban (1989-1991)
- Chevrolet V20 (1987)
- Chevrolet V20 Suburban (1987-1988)
- Chevrolet V2500 Suburban (1989-1991)
- Chevrolet V30 (1987-1988)
- Chevrolet V3500 (1989-1991)
- Chevrolet Venture (1997-2003)
- Daewoo Lanos (1999-2002)
- Dodge Monaco (1990-1992)
- Eagle Premier (1988-1992)
- GMC B6000 (1990-1991)
- GMC B7 (1993-1998)
- GMC C1500 (1984, 1988-1996)
- GMC C1500 Suburban (1984, 1992-1995)
- GMC C2500 (1984, 1988-1996)
- GMC C2500 Suburban (1992-1995)
- GMC C3500 (1988-1995)
- GMC C3500HD (1991-1995, 1997)
- GMC C5000 Topkick (1990-1991)
- GMC C6000 (1989-1990)
- GMC C6000 Topkick (1990-1996)
- GMC C6500 Topkick (1997-1998)
- GMC C7000 (1989-1990)
- GMC C7000 Topkick (1990-1996)
- GMC C7500 Topkick (1997-1998)
- GMC Caballero (1985-1987)
- GMC G1500 (1987-1995)
- GMC G2500 (1985, 1987-1995)
- GMC G3500 (1987-1996)
- GMC Jimmy (1984, 1987-1994)
- GMC K1500 (1984, 1988-1998)
- GMC K1500 Suburban (1984, 1992-1999)
- GMC K2500 (1984, 1988-1999)
- GMC K2500 Suburban (1992-1999)
- GMC K3500 (1988-1995, 1997-1999)
- GMC P2500 (1988-1989)
- GMC P3500 (1987-1999)
- GMC P6500 (1992-1996)
- GMC R1500 (1987)
- GMC R1500 Suburban (1987-1991)
- GMC R2500 (1987-1989)
- GMC R2500 Suburban (1987-1991)
- GMC R3500 (1987-1991)
- GMC S15 (1985-1990)
- GMC S15 Jimmy (1984-1991)
- GMC Safari (1985-1991)
- GMC Savana 1500 (1996)
- GMC Savana 2500 (1996-1999)
- GMC Savana 3500 (1997-1999)
- GMC Sonoma (1991-1997)
- GMC T6500 (1997-1998)
- GMC T7500 (1997-1998)
- GMC V1500 (1987)
- GMC V1500 Suburban (1987-1991)
- GMC V2500 (1987)
- GMC V2500 Suburban (1987-1991)
- GMC V3500 (1987-1991)
- GMC Yukon (1992-1997)
- Geo Storm (1990-1993)
- Honda Passport (1994-1997)
- Isuzu Amigo (1989-1994)
- Isuzu Hombre (1996-1997)
- Isuzu Impulse (1990-1992)
- Isuzu NPR (1993-1995)
- Isuzu Pickup (1989-1995)
- Isuzu Rodeo (1991-1997)
- Isuzu Stylus (1991-1993)
- Isuzu Trooper (1988-1997)
- Jeep CJ7 (1986)
- Jeep Cherokee (1986-1996)
- Jeep Comanche (1986-1992)
- Jeep Grand Cherokee (1993-1995, 2022)
- Jeep Grand Wagoneer (1986-1991)
- Jeep J10 (1986-1988)
- Jeep J20 (1987-1988)
- Jeep Wagoneer (1987-1990)
- Jeep Wrangler (1987-1995)
- Oldsmobile Achieva (1992-1998)
- Oldsmobile Alero (1999-2004)
- Oldsmobile Bravada (1991)
- Oldsmobile Calais (1985-1987)
- Oldsmobile Custom Cruiser (1988-1992)
- Oldsmobile Cutlass (1987-1999)
- Oldsmobile Cutlass Calais (1988-1991)
- Oldsmobile Cutlass Ciera (1982-1996)
- Oldsmobile Cutlass Cruiser (1987-1994)
- Oldsmobile Cutlass Supreme (1988-1997)
- Oldsmobile Delta 88 (1991)
- Oldsmobile Firenza (1982-1988)
- Oldsmobile Omega (1982-1984)
- Oldsmobile Silhouette (1990-1994, 1996-2004)
- Pontiac 6000 (1982-1991)
- Pontiac Aztek (2001-2003)
- Pontiac Bonneville (1986)
- Pontiac Fiero (1984-1988)
- Pontiac Firebird (1982-1986, 1988-1997)
- Pontiac Grand Am (1985-2004)
- Pontiac Grand Prix (1986-2003)
- Pontiac J2000 (1982-1983)
- Pontiac J2000 Sunbird (1984-1985)
- Pontiac LeMans (1988-1993)
- Pontiac Montana (1999-2004)
- Pontiac Parisienne (1985-1986)
- Pontiac Phoenix (1981-1984)
- Pontiac Safari (1989)
- Pontiac Sunbird (1986-1994)
- Pontiac Sunfire (1995-1997)
- Pontiac Trans Sport (1990-1998)
- Renault Alliance (1983-1987)
- Renault Encore (1984-1986)
- Saturn SC (1991-1992)
- Saturn SC1 (1993-2002)
- Saturn SC2 (1993-1999)
- Saturn SL (1991-2002)
- Saturn SL1 (1991-2002)
- Saturn SL2 (1991-1999)
- Saturn SW1 (1993-1999)
- Saturn SW2 (1993-1999)
