NGK SPARK PLUGS BMR6A SOLID S25 Part Description
Manufacturer
Product Description
NGK Standard Spark Plug Shop Pack
Features & Benefits
- ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction nickel alloy center electrode provides consistent performance
- RECOMMENDED USAGE: Best for vehicles with OE nickel alloy plugs, not recommended on vehicles with factory precious metal plugs
- NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
NGK SPARK PLUGS BMR6A SOLID S25 Specifications
Product Attributes
| Short Style Spark Plug | Yes |
| Service Number | BMR6A SOLID S25 |
| Part Number | BMR6A SOLID S25 |
| Stock Number | 96686 |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Standard |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | Yes |
| Grade Type | Standard Replacement |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | .028 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 3/4" (19mm) |
| Insulator Height | 1.46 IN |
| Manufacturer Heat Range | 6 |
| Seat Type | Flat |
| Reach | 0.375 IN |
| Thread Diameter | 0.551 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.04 IN |
| Center Electrode Design | Standard |
| Washer Type | Crush |
| Center Electrode Projection | Non-Projected |
| Metallurgy | Copper |
| Thread Type Standard | Metric |
| Pre-Gap Size | 0.7 MM |
| Insulator Height | 37.0 MM |
| Reach | 9.5 MM |
| 6648 | 0.0 MM |
| Thread Size | M14 - 1.25 |
| Center Electrode Insulator Tip Projection | 1.0 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| UPC | 00087295866863 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS BMR6A SOLID S25 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | CSR45 |
| Autolite | 245, XST254DP, XST255DP |
| Briggs & Stratton | 293918 |
| Champion Spark Plug | 840C, RCJ8, 840 |
| DENSO Auto Parts | 6025, W20M-U, 6022, W20MR-U |
| E3 Spark Plugs | E3.12, FF-12 |
| Hitachi Construction Machinery | 018-00546-211 |
| Honda | 98073-56744 |
| Kawasaki | 92070-2060 |
| Kohler | 4113202S |
| Kubota | E7199-67740 |
| Motorcraft | AR7N |
| N/A | 7810, CJ86, 6036, A7NU, 254DP, CS45, 298808, AW5C, 98073-56740, FR63087A, TY6123, 07909-2225-0, 065-01404-60, 150265050, L6C, 90890-78074, 4051, 018-00502-210, 92070-2051, 77-404, A425213-0010, W20M-US, W20M, A3NX, A7N, A7NX, 7542, WS7E, WS8E, 7543, CW6CE, CW6NE, 77-302, T07900028, 843-1, 5846, CJ11, 5846S, 235, 254, SE254DPT, 159010-00330, A425308-0010, 159010-10130, A425306-0310, A425306-0311, BMR6A SOLID S25 |
| NGK | 96686 |
| Oregon | 77-306 |
| Robin | 065-01404-70 |
| Shibaura | 150265060 |
| Torch | L6RC |
