Aftermarket Replacement Hydraulic Filter, 60 Micron Wire Mesh, 13.78 in. Height
| Outside Diameter Top | 3.62 |
| Inide Diameter Top | 0.45 |
| Outside Diameter Bottom | 3.62 |
| Inside Diameter Bottom | 2.52 |
| Collapse Pressure | 145 |
| Operating Temp Min F | -13 |
| Operating Temp Max F | 248 |
| Filter Area sq in | 359 |
| Flow Direction | Inside-Out |
| Gasket Material | Buna |
| Fluid Type | HH / HL / HM / HV |
| Micron 1 | 60 |
| Bottom Inside Diameter | 2 13/25 in. |
| Bottom Outside Diameter | 3.62 in. |
| Cracking Pressure | 145 psi |
| Collapse Pressure | 145 psi |
| Filter Media | Wire Mesh |
| Filter Rating | 60 micron |
| Flow Direction | Inside Out |
| Filter Size | 359 sq. in. |
| Flow Type | Inside Out |
| Fluid Type | HL, HM, HV, HH |
| Gasket Material | Buna N |
| Height | 13.78 in. |
| Minimum Operating Temperature | -13-deg. F |
| Maximum Operating Temperature | 248-deg. F |
| Seal Type | Buna N |
| Top Inside Diameter | 0.45 in. |
| Top Outside Diameter | 3.62 in. |
| Brand | Part Number |
|---|---|
| HIFI | SH54038 |
