(888) 312-8812 Login SignupMAIN FILTER MF0489759 Aftermarket Replacement Hydraulic Filter with 125 Micron Rating, Wire Mesh, Outside-In Flow
Tap to view 2 more
MSRP: $52.60
$4899
Save $3.61
Limited availability at this price!
In Stock
Get it by Friday, Feb 27
MAIN FILTER MF0489759 Part Description
Manufacturer
Features & Benefits
- Interchange/replacement for OEM BALDWIN p/n PT9331
- Compatible with OEM filter in fit, form and function
- All of our elements are manufactured following ISO specifications.
- Buy hydraulic filters direct from the manufacturer
- Built using Quality Components with strict quality control.
- Main Filter MF0489759 replaces OEM PT9331 by BALDWIN and is compatible in fit, form and function.
- All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
- All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
- Images may be a general representations of products
Technical Specifications
| Outside Diameter Top | 3.386 |
| Outside Diameter Bottom | 3.386 |
| Thread Size | 2 |
| Threads | BSP |
| Collapse Pressure | 15 |
| Flow Rate GPM | 40 |
| Operating Temp Min F | -13 |
| Operating Temp Max F | 248 |
| Filter Area sq in | 235 |
| Flow Direction | Outside-In |
| Fluid Type | HH / HL / HM / HV |
| Micron 1 | 125 |
| bypass | No |
| handle | No |
| wrap | No |
Features & Benefits
- Interchange/replacement for OEM BALDWIN p/n PT9331
- Compatible with OEM filter in fit, form and function
- All of our elements are manufactured following ISO specifications.
- Buy hydraulic filters direct from the manufacturer
- Built using Quality Components with strict quality control.
- Main Filter MF0489759 replaces OEM PT9331 by BALDWIN and is compatible in fit, form and function.
- All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
- All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
- Images may be a general representations of products
MAIN FILTER MF0489759 Specifications
Product Attributes
| Bypass | No |
| Handle | No |
| Maximum Operating Temperature | 248 Deg Fahrenheit |
| Flow Direction | Outside-In |
| Collapse Pressure | 15 |
| Flow Rater | 40 GPM |
| Filter Area (sq. in.) | 235 |
| Fluid Type | HH / HL / HM / HV |
| Micron Rating | 125 |
| Height (in.) | 10.24 |
| Outside Diameter (Top) | 3.39 in. |
| Minimum Operating Temperature | -13 Deg Fahrenheit |
| Product Media | Wire Mesh |
| Thread Size | 2 |
| Thread Type | BSP |
| Wrap | No |
MAIN FILTER MF0489759 Cross References
| Brand | Part Number |
|---|---|
| BALDWIN | PT9331 |
