(888) 312-8812 Login SignupMAIN FILTER MF0617631 Aftermarket Replacement Hydraulic Filter with 25 Micron Rating, Cellulose, Outside-In Flow
Tap to view 2 more
MSRP: $28.85
$2799
Save $0.86
Limited availability at this price!
In Stock
Get it by Friday, Jan 9
MAIN FILTER MF0617631 Part Description
Manufacturer
Features & Benefits
- Interchange/replacement for OEM IKRON p/n HHC03934
- Compatible with OEM filter in fit, form and function
- All of our elements are manufactured following ISO specifications.
- Buy hydraulic filters direct from the manufacturer
- Built using Quality Components with strict quality control.
- Main Filter MF0617631 replaces OEM HHC03934 by IKRON and is compatible in fit, form and function.
- All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
- All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
- Images may be a general representations of products
Technical Specifications
| Outside Diameter Top | 2.756 |
| Inide Diameter Top | 1.161 |
| Outside Diameter Bottom | 2.756 |
| BPVS Setting PSI | 25 |
| Collapse Pressure | 44 |
| Operating Temp Min F | -13 |
| Operating Temp Max F | 248 |
| Capacity gr | 6.1566 |
| Filter Area sq in | 154 |
| Flow Direction | Outside-In |
| Gasket Material | Viton |
| Fluid Type | HH / HL / HM / HV |
| Beta Ratio 1 | 2/25 |
| Micron 1 | 25 |
Features & Benefits
- Interchange/replacement for OEM IKRON p/n HHC03934
- Compatible with OEM filter in fit, form and function
- All of our elements are manufactured following ISO specifications.
- Buy hydraulic filters direct from the manufacturer
- Built using Quality Components with strict quality control.
- Main Filter MF0617631 replaces OEM HHC03934 by IKRON and is compatible in fit, form and function.
- All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
- All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
- Images may be a general representations of products
- Interchange/replacement for OEM IKRON p/n HHC03934
- Main Filter MF0617631 replaces OEM HHC03934 by IKRON and is compatible in fit, form and function.
- All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
MAIN FILTER MF0617631 Specifications
Product Attributes
| Height (in.) | 3.47 |
| Product Media | Cellulose |
| Handle | Yes |
| Bypass | Yes |
| Wrap | No |
| Micron Rating | 25 |
| Inside Diameter (Top) | 1.16 in. |
| Outside Diameter (Bottom) | 2.76 in. |
| Outside Diameter (Top) | 2.76 in. |
| Collapse Pressure | 44 |
| Maximum Operating Temperature | 248 Deg Fahrenheit |
| BPVS Setting (PSI) | 24.7 |
| Minimum Operating Temperature | -13 Deg Fahrenheit |
| Dust Holding Capacity | 6.16 grams |
| Gasket Material | Viton |
| Filter Area (sq. in.) | 154 |
| Flow Direction | Outside-In |
| Fluid Type | HH / HL / HM / HV |
| Beta Ratio 1 | 2/25 |
MAIN FILTER MF0617631 Cross References
We have 1 alternatives for the MF0617631 by MAIN FILTER:
MAIN FILTER MF0617631 Customer Reviews
No reviews yet
Be the first to review this product!
