Name: Main Filter MF0308839 Aftermarket Replacement Hydraulic Filter with 3 Micron Rating, Glass, Outside-In Flow
SKU: mf0308839
Price: 92.49 USD
Availability: InStock

MAIN FILTER part description

Technical Specifications

Outside Diameter Top	2.008
Inide Diameter Top	0.937
Outside Diameter Bottom	2.008
Collapse Pressure	3045
Operating Temp Min F	-13
Operating Temp Max F	248
Capacity gr	21.233357
Filter Area sq in	227
Flow Direction	Outside-In
Gasket Material	Viton
Fluid Type	HH / HL / HM / HV
Beta Ratio 1	200/3
Beta Ratio 2	1000/4.5
Micron 1	3

Features & Benefits

Interchange/replacement for OEM FLEETGUARD p/n HF7510
Compatible with OEM filter in fit, form and function
All of our elements are manufactured following ISO specifications.
Buy hydraulic filters direct from the manufacturer
Built using Quality Components with strict quality control.
Main Filter MF0308839 replaces OEM HF7510 by FLEETGUARD and is compatible in fit, form and function.
All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
Images may be a general representations of products
Main Filter MF0308839 replaces OEM HF7510 by FLEETGUARD and is compatible in fit, form and function.
All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
Images may be a general representations of products

Features & Benefits

Interchange/replacement for OEM FLEETGUARD p/n HF7510
Compatible with OEM filter in fit, form and function
All of our elements are manufactured following ISO specifications.
Buy hydraulic filters direct from the manufacturer
Built using Quality Components with strict quality control.
Main Filter MF0308839 replaces OEM HF7510 by FLEETGUARD and is compatible in fit, form and function.
All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
Images may be a general representations of products

Product Attributes

Handle	No
Micron Rating	3
Height (in.)	8.14
Outside Diameter (Top)	2.01 in.
Outside Diameter (Bottom)	2.01 in.
Minimum Operating Temperature	-13 Deg Fahrenheit
Wrap	No
Fluid Type	HH / HL / HM / HV
Beta Ratio 1	200/3
Beta Ratio 2	1000/4.5
Collapse Pressure	3045
Gasket Material	Viton
Filter Area (sq. in.)	227
Flow Direction	Outside-In
Product Media	Glass
Dust Holding Capacity	21.23 grams
Maximum Operating Temperature	248 Deg Fahrenheit
Inside Diameter (Top)	0.94 in.
Bypass	No

Part Interchanges

Fleetguard HF7510

MAIN FILTER MF0308839 Cross Reference

We have 1 alternatives for the MF0308839 by MAIN FILTER:

FLEETGUARD HF7510
