Name: Main Filter MF0693464 Aftermarket Replacement Hydraulic Filter with 5 Micron Rating, Glass, Outside-In Flow
SKU: mf0693464
Price: 131.99 USD
Availability: InStock

MAIN FILTER part description

Technical Specifications

Outside Diameter Top	3.563
Inide Diameter Top	1.898
Outside Diameter Bottom	3.563
Collapse Pressure	435
Operating Temp Min F	-13
Operating Temp Max F	248
Capacity gr	96.3634225
Filter Area sq in	1028
Flow Direction	Outside-In
Gasket Material	Viton
Fluid Type	HH / HL / HM / HV
Beta Ratio 1	200/5.4
Beta Ratio 2	1000/7.7
Micron 1	5

Features & Benefits

Interchange/replacement for OEM FLEETGUARD p/n HF30100
Compatible with OEM filter in fit, form and function
All of our elements are manufactured following ISO specifications.
Buy hydraulic filters direct from the manufacturer
Built using Quality Components with strict quality control.
Main Filter MF0693464 replaces OEM HF30100 by FLEETGUARD and is compatible in fit, form and function.
All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
Images may be a general representations of products
All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
Images may be a general representations of products

Features & Benefits

Interchange/replacement for OEM FLEETGUARD p/n HF30100
Compatible with OEM filter in fit, form and function
All of our elements are manufactured following ISO specifications.
Buy hydraulic filters direct from the manufacturer
Built using Quality Components with strict quality control.
Main Filter MF0693464 replaces OEM HF30100 by FLEETGUARD and is compatible in fit, form and function.
All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
Images may be a general representations of products

Product Attributes

Product Media	Glass
Height (in.)	12.91
Bypass	No
Handle	No
Micron Rating	5
Minimum Operating Temperature	-13 Deg Fahrenheit
Wrap	No
Fluid Type	HH / HL / HM / HV
Outside Diameter (Top)	3.56 in.
Inside Diameter (Top)	1.9 in.
Outside Diameter (Bottom)	3.56 in.
Collapse Pressure	435
Maximum Operating Temperature	248 Deg Fahrenheit
Filter Area (sq. in.)	1028
Gasket Material	Viton
Beta Ratio 1	200/5.4
Flow Direction	Outside-In
Beta Ratio 2	1000/7.7
Dust Holding Capacity	96.36 grams

Part Interchanges

Fleetguard HF30100

MAIN FILTER MF0693464 Cross Reference

We have 1 alternatives for the MF0693464 by MAIN FILTER:

FLEETGUARD HF30100
