(888) 312-8812 Login SignupMAIN FILTER MF0693449 Aftermarket Replacement Spin-On Fuel Filter with 20 Micron Rating, Glass, Outside-In Flow
$5849
Limited availability at this price!
In Stock
Get it by Tuesday, Aug 11
MAIN FILTER MF0693449 Part Description
Manufacturer
Features & Benefits
- Interchange/replacement for OEM FLEETGUARD p/n HF29107
- Compatible with OEM filter in fit, form and function
- All of our elements are manufactured following ISO specifications.
- Buy hydraulic filters direct from the manufacturer
- Built using Quality Components with strict quality control.
- Main Filter MF0693449 replaces OEM HF29107 by FLEETGUARD and is compatible in fit, form and function.
- All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
- All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
- Images may be a general representations of products
Technical Specifications
| Outside Diameter Top | 5.06 |
| Outside Diameter Bottom | 5.06 |
| Thread Size | 1.5 |
| Threads | 16 UNF |
| ADBV | NO |
| Burst Pressure | 261 |
| Collapse Pressure | 145 |
| Flow Rate GPM | 40 GPM |
| Operating Temp Min F | -13 |
| Operating Temp Max F | 248 |
| Flow Direction | Outside-In |
| Gasket Material | Buna |
| Fluid Type | HH / HL / HM / HV |
| Beta Ratio 1 | 200/20.7 |
| Beta Ratio 2 | 1000/26.6 |
| Micron 1 | 25 |
Features & Benefits
- Interchange/replacement for OEM FLEETGUARD p/n HF29107
- Compatible with OEM filter in fit, form and function
- All of our elements are manufactured following ISO specifications.
- Buy hydraulic filters direct from the manufacturer
- Built using Quality Components with strict quality control.
- Main Filter MF0693449 replaces OEM HF29107 by FLEETGUARD and is compatible in fit, form and function.
- All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
- All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
- Images may be a general representations of products
- All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
MAIN FILTER MF0693449 Specifications
Product Attributes
| Burst Pressure | 261 |
| Beta Ratio 1 | 200/20.7 |
| Beta Ratio 2 | 1000/26.6 |
| Flow Direction | Outside-In |
| Filter Area (sq. in.) | 633 |
| Micron Rating | 20 |
| Handle | No |
| Height (in.) | 6.94 |
| Minimum Operating Temperature | -13 Deg Fahrenheit |
| Outside Diameter (Top) | 5.06 in. |
| ADBV | No |
| Product Media | Glass |
| Bypass | No |
| Collapse Pressure | 145 |
| Fluid Type | HH / HL / HM / HV |
| Thread Size | 1.5 |
| Maximum Operating Temperature | 248 Deg Fahrenheit |
| Gasket Material | Buna |
| Flow Rater | 40 GPM |
| Thread Type | UNF |
| Wrap | No |
MAIN FILTER MF0693449 Cross References
| Brand | Part Number |
|---|---|
| FLEETGUARD | HF29107 |
