DYNAMIC FRICTION COMPANY part description

Hi- Carbon Alloy GEOMET Coated

Product Description

Hi- Carbon Alloy GEOMET Coated

Features & Benefits

  • Original Equipment (OE) Vane Configuration To Ensure Proper And Maximum Heat Dissipation
  • 100% Precision Mill-Balanced For Smoother Stopping And Zero Vibration At Any Speed
  • Disc Thickness Variation (DTV) - 010 MM Maximum
  • Fined Turned Finish (16 RMS) For Improved Initial Rotor And Pad Break-In
  • Engineered With Premium G3000/G11H18 Iron Castings For Strength, Stability, And Durability
  • Geomet® Coated To Provide High-Performance Corrosion Protection
  • Lateral Runout - 050 MM Maximum

Product Attributes

Height 54.9 MM
Inside Diameter 67 MM
22 5 EA
Solid Or Vented Type Rotor Vented
Outside Diameter 350 MM
Discard Thickness 29.4 MM
Nominal Thickness 32 MM
152 15.3 MM
Hat Finish GEOMET Grey
Rust Resistant Coating Yes
Overall Height 54.9 MM
Surface Type Smooth
Center Hole Diameter 67 MM
Stud/Lug Hole Quantity 5
Stud/Lug Hole Diameter 15.3 MM
9540 Non-Directional
9692 112 MM

Additional Information

Country of Origin (Primary) CN
Harmonized Tariff Code (Schedule B) 87083050
UPC 00190920057991

Fits Vehicles

  • Mercedes-Benz GLS450 (2017-2019)
  • Mercedes-Benz GLS350d (2017)
  • Mercedes-Benz GLE400 (2019)
  • Mercedes-Benz GL450 (2014-2016)
  • Mercedes-Benz GL350 (2013-2016)
