(888) 312-8812 Login SignupHALDEX APC71S4X2 Air Brake Air Line Connector Fitting - Male Run Tee, Swivel, 1/4 Tube Size, 1/8-27 Pipe Thread
MSRP: $9.32
$699
Save $2.33
Limited availability at this price!
In Stock
Get it by Friday, Dec 19
HALDEX APC71S4X2 Part Description
Manufacturer
Product Description
Composite Male Run Tee Swivel 1/4T 1/8P Sold in quantities of 5
Features & Benefits
- With a typical temperature range from -40° to 200°F
- Made compatible with J844 and 49 CFR 571.106 air brake tubing
- With polybutylene terephthalate construction for superior durability
- Built to offer years of reliable use
Haldex Midland Composite Male Run Tee Swl
The Haldex Midland composite male run tee swl is a crucial air brake system component specifically designed to connect different kinds of tube. A part of Haldex’s comprehensive range of air brake air line connector fittings, this air-push connect fitting with swivel feature is made to conform and meet FMVSS 571.0106, SAE J1131, J2494 1, and J2494 3 air brake performance requirements.
HALDEX APC71S4X2 Specifications
Product Attributes
| Center to End 1 Length | 0.92 in. |
| Center to End 2 Length | 0.81 in. |
| Center to End 3 Length | 0.81 in. |
| Connector Gender | Male |
| End 1 Inside Diameter | 1/4 in. |
| End 2 Inside Diameter | 1/4 in. |
| Freight Class | 70 |
| Hex Size | 9/16 in. |
| Material | Composite |
| Pipe Diameter | 1/8-27 in. NPT |
| Tubing Outside Diameter | 0.52 in. |
| Type | Swivel Run Tee |
Additional Information
| Country of Origin (Primary) | SG |
| Harmonized Tariff Code (Schedule B) | 7412200035 |
| Harmonized Tariff Code (HTS) | 7412200035 |
| Remanufactured Part | N |
| Warranty Distance | 100000 |
| Warranty Distance UOM | MI |
| Warranty Special | 24 MO, 200,000 MI=All Other Tour Bus, Intercity Transit Products Not Listed(8). 12MO,100,000 MI= All Other New Products Not Listed(13), City Transit Oper.(9) (All New Products), Friction Products(7), New Clutches(6). See L20221W.pdf for warranty details |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 00767653392394 |
| VMRS Code | 013010002 |
HALDEX APC71S4X2 Part Interchanges
| Brand | Part Number |
|---|---|
| N/A | 016400 |
| Velvac | 016400 |
HALDEX APC71S4X2 Manufacturer Information
Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
