(888) 312-8812 Login SignupFLEETGUARD AF860 Air Filter - Primary, With Gasket/Seal, 14.51 in. (Height), 12.1 in. OD
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
FLEETGUARD AF860 Part Description
FLEETGUARD AF860 Specifications
Product Attributes
| Height | 14.51 in. (368.55 mm) |
| Gasket Or Seal Included | Yes |
| Bottom Inside Diameter | 0.67 in. (17.02 mm) |
| Bottom Outside Diameter | 12.08 in. (306.83 mm) |
| Top Inside Diameter | 5.69 in. (144.53 mm) |
| Notes | Primary |
| End 1 Id | 5.69 in |
| End 2 Id | 16.89 mm |
| End 2 Od | 306.88 mm |
| Largest Od | 307.34 mm |
| Overall Height | 368.43 mm |
Additional Information
| Warranty Distance | 100000 |
| Warranty Distance UOM | DH |
| Warranty Time | 1 |
| Warranty Time UOM | YR |
FLEETGUARD AF860 Cross References
| Brand | Part Number |
|---|---|
| AC | A469C |
| Air Refiner | ARM118954, ARM181010 |
| BALDWIN | PA2316 |
| Caterpillar | 7C8329 |
| Champ | AF8954, LAF8954 |
| Cyclone | PMA118954 |
| Donaldson | SMP181010, P118954, P181010 |
| FRAM | CA582 |
| GMC | 6487716, 681715, 681716, 684743716, 699605, 8881285 |
| Guardian | G118954 |
| Kralinator | LA554 |
| LUBER-FINER | LAF8954 |
| Nelson | 121471, 70145N |
| WIX FILTERS | WIX FILTERS, 42957 |
| Woodgate | WGA611 |
