DELPHI TC6391 - Control Arm and Ball Joint Assembly
$13699
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
California Proposition 65 Warning
California Proposition 65 Warning
WARNING: This product can expose you to chemicals including Carbon black, which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov. (Read more)
Product Description
Control Arm and Ball Joint Assembly
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Left Lower Rearward |
| Pre-Greased | No |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Mounting Type | Machined |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Casting/Forged |
| Control Arm Material | Aluminum |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 1 |
| Adjustable | No |
| Greasable | No |
| Control Arm Maximum Width | 8.268 IN |
| Control Arm Maximum Width | 210.0 MM |
| Control Arm Color | Silver |
| Ball Joint Thread Diameter | 14.0 MM |
| Ball Joint Stud Length | 85.0 MM |
| Control Arm Maximum Length | 16.339 IN |
| Control Arm Maximum Length | 415.0 MM |
| Mounting Hole Diameter | 12.2 MM |
| Bushing Material | Rubber |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708806590 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708807000 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604328361 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
Part Interchanges
Fits Vehicles
- Audi RS7 (2014-2018)
- Audi A6 Quattro (2012-2018)
- Audi S6 (2013-2018)
- Audi S7 (2013-2018)
- Audi A6 (2012-2018)
- Audi A7 Quattro (2012-2018)
