(888) 312-8812 Login SignupDELPHI TC6367 Control Arm and Ball Joint Assembly
Tap to view 13 more
$7849
Limited availability at this price!
In Stock
Get it by Tuesday, Feb 10
DELPHI TC6367 Part Description
Manufacturer
Product Description
Control Arm and Ball Joint Assembly
Features & Benefits
- Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Control arms utilize robot welding for consistent performance and quality
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC6367 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Right Lower |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Mounting Type | Bolt In |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Stamped |
| Control Arm Material | Steel |
| Mounting Hardware Included | Yes |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 4.213 IN |
| Control Arm Maximum Width | 107.00 MM |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 0.551 IN |
| Ball Joint Thread Diameter | 14.00 MM |
| Ball Joint Stud Length | 0.906 IN |
| Ball Joint Stud Length | 23.00 MM |
| Control Arm Maximum Length | 17.878 IN |
| Control Arm Maximum Length | 454.10 MM |
| Bushing Material | Rubber |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Thread Diameter | 14.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Thread Diameter | 0.551 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708806590 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708807000 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604321904 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC6367 Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 102-6236 |
| DORMAN | CA74544, CA74544PR, CA74654PR, CA74654 |
| Dorman | 520-456, 524-138 |
| MAS Industries | CA74544, CA74544PR |
| MEVOTECH | CMS86148 |
| MOOG | RK620578 |
| MOOG Chassis Products | RK620578, 102-6236 |
| N/A | 43330-39435, 43330-39285, GS86148, CMS86148, 622.44043, 521-730 |
| TRW | JTC2502 |
| Toyota | 48068-07030, 48068-08011 |
DELPHI TC6367 Fits Vehicles
- Toyota Solara (1999-2003)
- Toyota Sienna (1998-2003)
- Toyota Avalon (1998-2004)
