(888) 312-8812 Login SignupDELPHI TC1297 Control Arm and Ball Joint Assembly
Tap to view 2 more
$8649
Limited availability at this price!
In Stock
Get it by Thursday, Feb 19
DELPHI TC1297 Part Description
Manufacturer
Product Description
Control Arm and Ball Joint Assembly
Features & Benefits
- Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Control arms utilize robot welding for consistent performance and quality
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC1297 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Left Lower |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Ball Joint Mounting Type | Press In |
| Control Arm Construction | Stamped |
| Control Arm Material | Steel |
| Mounting Hole Quantity | 3 |
| Adjustable | No |
| Greaseable | No |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 14.00 MM |
| Ball Joint Thread Diameter | 0.551 IN |
| Ball Joint Stud Length | 22.00 MM |
| Ball Joint Stud Length | 0.866 IN |
| Bushing Material | Rubber |
| Mounting Hole Diameter | 14.00 MM |
| Mounting Hole Diameter | 0.551 IN |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Bushings Included | Yes |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Thread Diameter | 14.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Thread Diameter | 0.551 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604269466 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC1297 Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-5557, 102-5557 |
| CORTECO | 49398887, 49398541 |
| Datsun/Nissan | 54501-F4600 |
| Dorman | 520-529, 523-611, CB69043, CB69043PR |
| MAS Industries | CB69033, CB69043, CB69043PR |
| MEVOTECH | CMS20462 |
| MOOG | RK620359 |
| MOOG Chassis Products | CK620359, K620359, RK620359, 102-5557 |
| Mevotech | MS20462 |
| N/A | 54501-4Z005, 5450195F0A, GS20462, CMS20462, 623.42021, 54501-5M000 |
| TRW | JTC7574 |
DELPHI TC1297 Fits Vehicles
- Nissan Sentra (2000-2006)
