DELPHI TA5539 Part Description
DELPHI TA5539 Specifications
Product Attributes
| Position(s) | Right |
| Item Grade | Standard Replacement |
| Length | 130.00 MM |
| Color | Black |
| End 1 Gender | Male |
| End 2 Gender | Male |
| Pre-Greased | Yes |
| Grease Fitting Included | Yes |
| Dust Boot Included | Yes |
| Width | 62 MM |
| Type | Straight |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 1.000 IN |
| End 2 Thread Diameter | 25.40 MM |
| Height | 108.70 MM |
| Housing Material | Steel |
| Tube Diameter | 1.000 IN |
| Tube Diameter | 25.40 MM |
| Adjustable | No |
| Greaseable | Yes |
| Weight | 2.53 lb |
| Cone Outside Diameter | 23.00 MM |
| Bearing Material | Steel |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| Stud Type | Threaded |
| Length - Stud Center to End | 3.937 IN |
| Length - Stud Center to End | 100.00 MM |
| Dust Boot Material | Rubber |
| Tie Rod Material | Steel |
| End 2 Threads Per Inch | 16 |
| End 1 Threads Per Inch | 16 |
| End 1 Thread Diameter | 0.750 IN |
| End 1 Thread Diameter | 19.05 MM |
| Shank Length | 23.00 MM |
| Stud Length | 23.00 MM |
| Grade Type | Standard |
| Grade | Premium |
| Shank Length | 0.906 IN |
| Stud Length | 0.906 IN |
| Cone Outside Diameter | 0.906 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708947550 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708947550 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604315781 |
| VMRS Code | 015004019 |
| UNSPSC | 25174205 |
DELPHI TA5539 Cross References
| Brand | Part Number |
|---|---|
| Chrysler | 1818854, A13144L194, A13144M195 |
| Ford | C1TZ-3A130B |
| International Harvester (IHC) | A13144M195 |
| MOOG Chassis Products | ES2083L, ES304R |
| TRW | JTE1641 |
DELPHI TA5539 Fits Vehicles
- Dodge Truck (1957-1960)
