WABCO 4235061210 - Air Brake Chamber - Unistop Series, Disc Brakes
$16099
MSRP: $185.78
Save: $24.79
In stock
limited availability at this price!
. Learn more
WABCO part description
Product Attributes
| Port Angle | 0° |
| Type | 24 |
| Distance between bolts | 120.6 mm |
| Stroke | 65.0 mm |
| Bolt Lengths | 43.0 mm |
| Clamp Band | 186 mm |
| Calculated Volume (dm³) | 5.3019 |
| Output Force | 8500 N |
| Type Of Operation | Disc |
| Clamp Band Position | -135° |
| Size | 171 x 195 x 159 |
| Push-Rod Length | 15 mm |
| Return-Spring Force | 210 N |
| Max. operating pressure | 10.2 bar |
| Port threads | M16 x 1.5 |
| Port (Side) | M16 x 1.5 JED-464-0 |
| Bolt Threads | M16 x 1.5 |
| Operating Pressure | 10.2 bar |
| Weight | 8.0888 |
| Total Length | 121.0 mm |
| Push-rod thread | Ball R8 |
| Version | Without boot |
| Port (Top) | M16 x 1.5 JED-464-0 |
| Output Force M | 8500 N |
| Temperature Range | -40°C to +80°C |
WABCO 4235061210 Cross Reference
We have 3 alternatives for the 4235061210 by WABCO:
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
