(888) 312-8812 Login SignupWABCO 4231060080 Air Brake Chamber - Unistop Series, Type 24
Tap to view 3 more
MSRP: $76.45
$6599
Save $10.46
Limited availability at this price!
In Stock
Get it by Tuesday, Dec 16
WABCO 4231060080 Part Description
WABCO 4231060080 Specifications
Product Attributes
| Total Length | 119.0 mm |
| Type | 24 |
| Clevis Pins | 12.9 mm |
| Distance between bolts | 120.6 mm |
| Max. operating pressure | 8.0 bar |
| Size | 100 x 100 x 400 |
| Port threads | 3/8" - 18 NPTF |
| Stroke | 75.9 mm |
| Output Force | 7500 N |
| Weight | 8.157 |
| Version | Without boot |
| Push-Rod Length | 90.2 mm |
| Yoke | With |
| Push-rod thread | 3/8" |
| Return-Spring Force | 175 N |
| Temperature Range | -40°C to +80°C |
| Calculated Volume (dm³) | 4 |
| Bolt Lengths | 39.0 mm |
| Bolt Threads | 5/8" - 11 UNC |
| Type Of Operation | Cam |
| Output Force M | 7500 N |
WABCO 4231060080 Cross References
We have 2 alternatives for the 4231060080 by WABCO:
WABCO 4231060080 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
