WABCO 4700511140 - Clutch Servo
$8,35349
MSRP: $10,644.18
Save: $2,290.69
Limited Availability
. Learn more
WABCO part description
Product Attributes
| Length | 292 mm |
| Temperature Range | -40°C to +80°C |
| Mounting | 4x Ø 9.0 mm |
| Weight | 5.741 |
| Stroke | 59.5 mm |
| Medium | Brake fluid and compressed air |
| Port thread 31 | Flap Exhaust |
| Max. operating pressure | 8.0 bar |
| Push-rod thread | Ball Ø 12.0 mm |
| Size | 137x294x126 |
| Distance Between Holes | 130 mm |
| Calculated Volume (dm³) | 5.075028 |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M14 x 1.5 |
| Port Thread 1-4 | M14 x 1.5 |
WABCO 4700511140 Cross Reference
We have 43 alternatives for the 4700511140 by WABCO:
- MERITOR S4700511140
- WABCO S4700511140
- DAF 0068057
- EVOBUS A0012954706
- DAF 68057
- FAUN 99708474796
- IVECO 81327356047
- FREIGHTLINER TDAS4700511140
- IVECO 8190494
- IVECO 0012954706
- IVECO 08122756
- IVECO 5000815677
- IVECO 957008
- IVECO 42481587
- IVECO 8122756
- KENWORTH S4700511140
- LEYLAND-DAF 68057
- LEYLAND-DAF 0068057
- MACK 6300-4700511140
- MAN 8190494
- MAN 81307256034
- MAN 81327356047
- MAN 5000815677
- MAN 8122756
- MAN 81307256012
- MERCEDES-BENZ 0012954706
- MAN 0012954706
- MERCEDES-BENZ 8122756
- MERCEDES-BENZ 5000815677
- MERCEDES-BENZ A0012954706
- MERCEDES-BENZ 8190494
- MERCEDES-BENZ 81327356047
- NEOPLAN 81307256034
- NEOPLAN 11009894
- PETERBILT S4700511140
- RENAULT 8122756
- RENAULT 5000815677
- RENAULT 0012954706
- RENAULT 81327356047
- RENAULT 5000806808
- RENAULT 8190494
- TEREX-DEMAG 22430940
- VOLVO WAB4700511140
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
