WABCO 4613180360 - Air Brake Foot Valve - ITT Cannon 4-pin, 45° Angle, 10.0 bar Max Pressure
$3,27649
MSRP: $4,175.00
Save: $898.51
Limited Availability
. Learn more
WABCO part description
Product Attributes
| Predominance | 0.30 bar |
| Temperature Range | -40°C to +80°C |
| Pedal Angle | 45° |
| Calculated Volume (dm³) | 15.0535 |
| Actuation | 4619087902 |
| Basic Valve | 4613154481 |
| Distance Between Holes | 80x180 mm |
| Electrical connection | ITT Cannon 4-pin |
| Exhaust | Flap |
| Size | 391 x 250 x 154 |
| Max. operating pressure | 145.0 psi |
| Mounting | 3x Ø 9.0 mm |
| Weight | 7.6258 |
| Port thread 21 | M16 x 1.5 |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
WABCO 4613180360 Cross Reference
We have 5 alternatives for the 4613180360 by WABCO:
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
