Name: Reach Cooling 42-10279 MITSUBISHI FUSO 96-- NON-USA MODELS
SKU: 4210279
Price: 556.49 USD
Availability: InStock

REACH COOLING part description

MITSUBISHI FUSO 96-- NON-USA MODELS

Product Description

MITSUBISHI FUSO 96-- NON-USA MODELS

Application Summary

MITSUBISHI FUSO 96-- NON-USA MODELS

Features & Benefits

Folded fin edges increase stability and heat disbursement properties.
Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
Our fin edges are folded for increased stability and heat disbursement properties.
Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.

Product Attributes

Core Thickness	2 3/16 IN
Inlet Header Length	760.4 MM
Core Row Quantity	2
Tank Material	Plastic
Outlet Diameter	68.3 MM
Core Width	28.666 IN
Outlet Header Length	29 15/16 IN
Core Material	Aluminum
Transmission Oil Cooler Included	No
Inlet Header Width	3 IN
Outlet Header Width	76.2 MM
Inlet Diameter	2 11/16 IN
Engine Oil Cooler Included	No
Core Height	33 7/16 IN
Core Height	849.3 MM
Inlet Header Length	29 15/16 IN
Inlet Header Width	76.2 MM
Outlet Header Width	3 IN
Inlet Location	Top Middle
Core Thickness	55.549 MM
Frame Included	No
Inlet Header Length	760.399 mm
Core Thickness	55.6 MM
Down Flow Or Cross Flow Type	Cross Flow
Core Height	849.299 MM
Inlet Diameter	68.249 mm
Inlet Header Width	76.2 mm
Outlet Header Length	760.399 mm
Outlet Header Width	76.2 mm
Core Width	728 MM
Outlet Location	Bottom Left
Inlet Diameter	68.3 MM
Outlet Diameter	2 11/16 IN
Radiator Cap Included	No
Core Width	728.116 MM
Outlet Diameter	68.249 MM
Outlet Header Length	760.4 MM

Additional Information

Country of Origin (Primary)	CN
Warranty Special	12 Months
UPC	06949521787240
VMRS Code	042002001
UNSPSC	25174002

Part Interchanges

Fits Vehicles

Mitsubishi Fuso FE-CA (2001)
Mitsubishi Fuso FG (1998-2001)
Mitsubishi Fuso FM-SR (1996-1997, 1999-2001)
Mitsubishi Fuso FM-SP (1996-2001)
Mitsubishi Fuso FM-MR (1996-2001)
Mitsubishi Fuso FM-HR (1996-2001)
Mitsubishi Fuso FH (1996-2001)
Mitsubishi Fuso FK (1996-2001)
Mitsubishi Fuso FE-SP (1996-2001)
Mitsubishi Fuso FE-HD (1996-2001)
Mitsubishi Fuso FE (1996-2001)
