REACH COOLING 41-2968 Radiator

(0)
41-2968 by REACH COOLING - Radiator
REACH COOLING
Tap to view 8 more

Out of Stock

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

REACH COOLING 41-2968 Part Description

Manufacturer

REACH COOLING

Product Description

Radiator

Application Summary

Lexus:2006-2015 IS250/ IS350

Features & Benefits

  • Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
  • Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
  • Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
  • Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
  • Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
  • Folded fin edges increase stability and heat disbursement properties.
  • Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
  • We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
  • Our fin edges are folded for increased stability and heat disbursement properties.
  • Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
  • Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
  • We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
  • Our utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.

No Shipping Restriction

radiator, complete, engine cooling, rad, cooling, heat, transfer

REACH COOLING 41-2968 Specifications

Product Attributes

Outlet Header Length 29 IN
Outlet Diameter 38.1 MM
Core Row Quantity 1
Engine Oil Cooler Included No
Core Height 14.75 IN
Inlet Location Top Left
Inlet Header Length 29 IN
Transmission Oil Cooler Included No
Outlet Header Width 50.80 MM
Inlet Diameter 1.5 IN
Core Width 712.8 MM
Core Thickness 0.625 IN
Core Material Aluminum
Radiator Cap Included Not Needed
Down Flow Or Cross Flow Type Down Flow
Inlet Header Width 50.80 MM
Outlet Location Bottom Right
Tank Material Plastic
Core Thickness 15.875 MM
Outlet Header Length 736.60 MM
Inlet Header Width 2 IN
Inlet Diameter 38.1 MM
Inlet Header Width 50.8 mm
Outlet Diameter 38.1 MM
Outlet Header Width 50.8 mm
Outlet Diameter 1.5 IN
Core Height 374.65 MM
Core Width 712.774 MM
Core Thickness 15.9 MM
Inlet Header Length 736.60 MM
Inlet Header Length 736.6 mm
Inlet Diameter 38.1 mm
Core Height 374.7 MM
Outlet Header Width 2 IN
Outlet Header Length 736.6 mm
Core Width 28.062 IN

Additional Information

Country of Origin (Primary) TH
UPC 08859869502598
VMRS Code 042002001
UNSPSC 25174002

REACH COOLING 41-2968 Cross References

BrandPart Number
1-800-Radiator103314
APDI8012968
APDI RADS8012968
Advance Auto Parts812968
AutoNation19812-01611
AutoZoneB2968
Autokool2968
BesutoBES2968
CRSCUC2968, CRS2968
CSF3295
Cancore IndustriesC2968
CryoMAX0R-002968-A1CM, 0R002968A1CM, 2968
DENSO221-3169, 2213169, 3169
DPI DataPoint Inc2968
Dixin USADX2968
FVPRAD2968
Factory AirRAD2968
Federated2968
FisherCU2968
FronteraAM2968
GLOBAL PARTS DISTRIBUTORS2968C
Genera - Archived2968
KlimotoKLI2968
Kool VueP2968
KoyoA2968
Lexus16400-31440, 1640031440
Lynol Cooling SystemsLR2968
Murray Heat Transfer434053, CU2968
NAPACU2968, NR2968A
Nissens64672, 646948
Northern RadiatorCR2968
OSC2968
Omega24-80917, 2480917
PACIFIC BEST INC.PR2968A
PBIPR2968A
PartslinkLX3010135
Performance Radiator2413
Platinum ProRAD2968
RadCool2968
Spectra PremiumCU2968
Sunbelt Radiators IncSBR2968
TYC2968
Tongshi75465, 75646, 7546516
UNIVERSAL AIR CONDITIONER (UAC)RA2968C
US Motor WorksUSR2968
Valeo701572
Vision2968

REACH COOLING 41-2968 Fits Vehicles

  • Lexus IS250 (2006-2015)
  • Lexus IS350 (2006-2015)
