REACH COOLING 41-2897 Part Description
Manufacturer
Product Description
Radiator
Features & Benefits
- Our B-type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
- Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
- Our fin edges are folded for increased stability and heat disbursement properties.
- Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
- Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
- We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
- We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
No Shipping Restriction
REACH COOLING 41-2897 Specifications
Product Attributes
| Core Height | 435 MM |
| Outlet Header Length | 30.312 IN |
| Core Height | 17.125 IN |
| Core Thickness | 0.625 IN |
| Inlet Header Length | 30.312 IN |
| Transmission Oil Cooler Type | Concentric |
| Core Width | 29.8 IN |
| Tank Material | Plastic |
| Transmission Oil Cooler Included | Yes |
| Outlet Header Length | 769.9 MM |
| Core Thickness | 15.9 MM |
| Core Width | 756.9 MM |
| Inlet Header Width | 39.7 MM |
| Inlet Diameter | 1.375 IN |
| Inlet Header Length | 769.9 MM |
| Transmission Oil Cooler Distance between Fittings | 17.375 IN |
| Radiator Cap Included | No |
| Inlet Header Width | 1.562 IN |
| Core Row Quantity | 1 |
| Transmission Oil Cooler Distance between Fittings | 441.3 MM |
| Outlet Header Width | 1.562 IN |
| Core Material | Aluminum |
| Inlet Location | Top Right |
| Engine Oil Cooler Included | No |
| Outlet Diameter | 34.9 MM |
| Outlet Location | Bottom Left |
| Outlet Header Width | 39.7 MM |
| Inlet Diameter | 34.9 MM |
| Outlet Diameter | 1.375 IN |
| Down Flow Or Cross Flow Type | Down Flow |
Additional Information
| Country of Origin (Primary) | TH |
| Harmonized Tariff Code (HTS) | 8708915000 |
| UPC | 08859869501782 |
| VMRS Code | 042002001 |
| UNSPSC | 25174002 |
REACH COOLING 41-2897 Cross References
| Brand | Part Number |
|---|---|
| 1-800-Radiator | 103150, 103377 |
| APDI | 8012997, 8012897 |
| APDI RADS | 8012897 |
| Advance Auto Parts | 812897 |
| AutoNation | 19812-01364 |
| AutoZone | B2997 |
| Besuto | BES2897 |
| CRS | CUC2997, CRS2997, CUC2897 |
| CSF | 3342 |
| Cancore Industries | C2897, C2997 |
| CryoMAX | 0R-002897-A1CM, 2897, 0R002897A1CM, 0R002997A1CM, 2997 |
| DENSO | 221-3705, 2213705 |
| DPI DataPoint Inc | 2897, 2997 |
| Dixin USA | DX2997, DX2897 |
| Factory Air | RAD2897, RAD2997 |
| Federated | 2897 |
| Fisher | CU2997 |
| Frontera | AM2897 |
| GLOBAL PARTS DISTRIBUTORS | 2897C |
| Genera - Archived | 2897, 2997G, 2897G |
| Hummer | 253100W000, 253100W100 |
| Hyundai | 253100W000, 253100W100, 253100W200, 253100W201 |
| Keystone Auto Industries | RAD2897, RAD2997 |
| Klimoto | KLI2897 |
| Kool Vue | P2897, P2997 |
| Koyo | A2897 |
| Lynol Cooling Systems | LR2997 |
| Murray Heat Transfer | 438157, 8012897 |
| NAPA | CU2997, NR2897A |
| Nissens | 67505 |
| Northern Radiator | CR2897, CR2997 |
| OEM | 253100000 |
| OSC | 2897, 2997, USR2897 |
| PACIFIC BEST INC. | PR2897A, PR2997A |
| PBI | PR2897A |
| Partslink | HY3010157 |
| Performance Radiator | 2495 |
| Platinum Pro | RAD2897 |
| RadCool | 2897, 2997 |
| Spectra Premium | CU2997, CU2897 |
| Sunbelt Radiators Inc | SBR2897 |
| TYC | 2897G, 2997G, 2897, 2897-G, 2997-G |
| TYG | HN37024A, HN37024B |
| Tongshi | 70053 |
| UNIVERSAL AIR CONDITIONER (UAC) | RA2897C |
| US Motor Works | USR2897, USR2997 |
| Vision | 2897, 2997 |
| Vista Pro | 438157, 8910 |
REACH COOLING 41-2897 Fits Vehicles
- Hyundai Santa Fe (2007-2009)
