DELPHI TC5224 Control Arm and Ball Joint Assembly

★★★★★ (0)
Delphi TC5224 Suspension Control Arm and Ball Joint Assembly Control Arm and Ball Joint Assembly
DELPHI
Tap to view 6 more

$86.99

Limited availability at this price!

In Stock

Get as soon as Monday, Nov 30
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details
Orders placed over the weekend will be processed the next business day.

DELPHI TC5224 Part Description

Manufacturer

DELPHI

Product Description

Control Arm and Ball Joint Assembly

Features & Benefits

  • Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
  • Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specfications
  • Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
  • Control arms utilize robot welding for consistent performance and quality
  • Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics

DELPHI TC5224 Specifications

Product Attributes

Item GradeStandard Replacement
Position(s)Front Right Lower
Pre-GreasedYes
Grease Fitting IncludedNo
Bushings IncludedYes
Ball Joint Mounting TypeBolt In
Ball Joint Stud TypeThreaded
Control Arm ConstructionStamped
Control Arm MaterialSteel
Mounting Hardware IncludedYes
Mounting Hole Quantity0
AdjustableNo
GreaseableNo
Control Arm Maximum Width15.748 IN
Control Arm Maximum Width400.00 MM
Control Arm ColorBlack
Ball Joint Thread Diameter0.551 IN
Ball Joint Thread Diameter14.00 MM
Ball Joint Stud Length2.362 IN
Ball Joint Stud Length60.00 MM
Control Arm Maximum Length15.945 IN
Control Arm Maximum Length405.00 MM
Bushing MaterialRubber
Thread DirectionClockwise (Right)
Bushing ColorBlack
FinishPainted
Dust Boot IncludedYes
Ball Joint IncludedYes
Grade TypePremium
Boot MaterialChloroprene Rubber (CR)
Locking Nut IncludedYes
Thread Diameter14.00 MM
Boot ColorBlack
Steering TypePower
Bearing MaterialPlastic
Dust Boot MaterialChloroprene Rubber (CR)
Thread Diameter0.551 IN

Additional Information

Harmonized Tariff Code (Schedule B)8708807000
Harmonized Tariff Code (HTS)8708806590
Warranty SpecialLimited
Warranty Special UOMLT
Country of Origin (Primary)CN
UPC00689604296301
VMRS Code016001001
UNSPSC25172013

DELPHI TC5224 Cross References

BrandPart Number
DORMANCB90424, 522-040, CB90424PR, 522-022
General Motors20774419
MAS IndustriesCB90424, CB90424PR
MEVOTECHCMS501017
MOOGRK621231
MOOG Chassis ProductsRK621231
N/A25798011, GS501017, 522-040, CMS501017, CK621231
TRWJTC2415
UNITY AUTOMOTIVESC-700043, CAB621231, 2C-CAB621232

DELPHI TC5224 Fits Vehicles

  • Buick Enclave (2008-2017)
  • Chevrolet Traverse (2009-2017)
  • GMC Acadia (2007-2016)
  • GMC Acadia Limited (2017)
  • Saturn Outlook (2007-2010)
