(888) 312-8812 Login SignupCENTRIC 320.50005 Centric GCX Rotor with Partial Coating
Tap to view 4 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 320.50005 Part Description
Manufacturer
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.50005 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Misc Holes [cntrc] | 2 |
| Vane Style [cntrc] | Straight |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 13.000 |
| Notes [cntrc] | Vented Hat |
| Weight [cntrc] Kgs | 5.910 |
| Discard Thickness | 0.866 IN |
| Discard Thickness | 22.000 MM |
| Nominal Thickness | 0.945 IN |
| Nominal Thickness | 24.000 MM |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 48.600 MM |
| Overall Height | 1.913 IN |
| Outside Diameter | 10.157 IN |
| Outside Diameter | 258.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 57.000 MM |
| Center Hole Diameter | 2.244 IN |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Stud/Lug Hole Quantity | 4 |
| Stud/Lug Hole Diameter | 13.000 MM |
| Stud/Lug Hole Diameter | 0.512 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590390513 |
CENTRIC 320.50005 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 980078R |
CENTRIC 320.50005 Cross References
We have 1 alternatives for the 320.50005 by CENTRIC:
