CENTRIC 320.02000 Part Description
Manufacturer
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.02000 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating / DIH |
| Weight [cntrc] Lbs | 11.000 |
| Weight [cntrc] Kgs | 5.000 |
| Misc Holes [cntrc] | 4 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 0.295 IN |
| Discard Thickness | 7.500 MM |
| Nominal Thickness | 9.400 MM |
| Nominal Thickness | 0.370 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 65.200 MM |
| Overall Height | 2.567 IN |
| Outside Diameter | 267.000 MM |
| Outside Diameter | 10.512 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 6.299 IN |
| Nominal Drum Diameter | 160.000 MM |
| Bearings Included | No |
| Center Hole Diameter | 2.756 IN |
| Center Hole Diameter | 70.000 MM |
| Mounting Bolt Hole Circle Diameter | 108.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.252 IN |
| Stud/Lug Hole Quantity | 4 |
| Stud/Lug Hole Diameter | 12.500 MM |
| Stud/Lug Hole Diameter | 0.492 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590386318 |
CENTRIC 320.02000 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 96804 |
CENTRIC 320.02000 Cross References
We have 1 alternatives for the 320.02000 by CENTRIC:
