CENTRIC 320.44017 Part Description
Manufacturer
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.44017 Specifications
Product Attributes
| Product Grade [cntrc] | Premium |
| Hat Id [cntrc] Mm | 123.700 |
| Weight [cntrc] Lbs | 10.750 |
| Hat Id [cntrc] In | 4.870 |
| Weight [cntrc] Kgs | 4.890 |
| Misc Holes [cntrc] | 0 |
| Disc Mounting [cntrc] | Behind the Hub |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Vane Style [cntrc] | Straight |
| Discard Thickness | 0.748 IN |
| Discard Thickness | 19.000 MM |
| Nominal Thickness | 20.000 MM |
| Nominal Thickness | 0.787 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 26.000 MM |
| Overall Height | 1.024 IN |
| Outside Diameter | 10.157 IN |
| Outside Diameter | 258.000 MM |
| Mounting Bolt Hole Quantity | 4 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.992 IN |
| Center Hole Diameter | 76.000 MM |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Mounting Bolt Hole Diameter | 10.700 MM |
| Mounting Bolt Hole Diameter | 0.421 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590389319 |
CENTRIC 320.44017 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 9221, 9221R |
CENTRIC 320.44017 Cross References
We have 2 alternatives for the 320.44017 by CENTRIC:
