Raybestos 782275R - Raybestos R-Line Brake Rotor
$7849
MSRP: $84.33
Save: $5.84
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
RAYBESTOS part description
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2017-2013 Jeep Wrangler Front, 2018 Jeep Wrangler JK Front
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.839 IN |
| Center Hole Diameter | 72.1 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.039 IN |
| Discard Thickness | 26.4 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 9.047 IN |
| Inside Diameter | 229.8 MM |
| Mounting Bolt Hole Circle Diameter | 5 IN |
| Mounting Bolt Hole Circle Diameter | 127 MM |
| Mounting Bolt Hole Diameter | 0.654 IN |
| Mounting Bolt Hole Diameter | 16.6 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.108 IN |
| Nominal Thickness | 28.15 MM |
| Outside Diameter | 13.071 IN |
| Outside Diameter | 332 MM |
| Overall Height | 2.173 IN |
| Overall Height | 55.2 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| UPC | 00887213306552 |
Part Interchanges
RAYBESTOS 782275R Cross Reference
We have 5 alternatives for the 782275R by RAYBESTOS:
Fits Vehicles
- Jeep Wrangler JK (2018)
- Jeep Wrangler (2013-2017)
