RAYBESTOS part description

Product Description

Raybestos R-Line Brake Rotor

Application Summary

2017-1999 Blue Bird All American FE Rear, 2018-2004 Blue Bird Vision School Bus Rear, 2005-1998 Freightliner FL70 Rear, 2009-2003 GMC C7500 Topkick Rear, 2005-1998 Freightliner FL60 Rear, 2009-2003 GMC C6500 Topkick Rear

Product Attributes

ABS Tone Ring Included Yes
Center Hole Diameter 9.12 IN
Center Hole Diameter 231.65 MM
9565 Conventional
Discard Thickness 1.42 IN
Discard Thickness 36.05 MM
Harmonize Code 8708.30.5030
Inside Diameter 10.07 IN
Inside Diameter 255.8 MM
Mounting Bolt Hole Circle Diameter 11.25 IN
Mounting Bolt Hole Circle Diameter 285.75 MM
Mounting Bolt Hole Diameter 0.934 IN
Mounting Bolt Hole Diameter 23.7 MM
Mounting Bolt Hole Quantity 10
Nominal Thickness 1.542 IN
Nominal Thickness 39.15 MM
Outside Diameter 15.377 IN
Outside Diameter 390.6 MM
Overall Height 7.606 IN
Overall Height 193.2 MM
Salability Restrictions No
Solid Or Vented Type Rotor Vented
Stud/Lug Hole Quantity 10
Surface Type Smooth
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) CN
UPC 00887213286496

Part Interchanges

Fits Vehicles

  • Freightliner FL70 (1998-2005)
  • Freightliner FL60 (1998-2005)
  • Freightliner FL50 (1998-2005)
  • Freightliner M2 (2006-2007)
  • Freightliner M2 100 (2006-2007)
  • Freightliner M2 112 (2006-2007)
  • Freightliner Business Class M2 (2006-2007)
  • Freightliner M2 106 (2006-2007)
  • Workhorse Custom Chassis W62 (2007-2012)
  • Workhorse W62 (2007-2011)
  • GMC T6500 (2004-2009)
  • Chevrolet T6500 (2004-2009)
  • Blue Bird Vision School Bus (2004-2018)
  • Blue Bird All American FE (1999-2017)
  • Workhorse Custom Chassis W24 (2004-2005, 2007-2009, 2011)
  • Blue Bird TC1000 (1998-2000)
  • Blue Bird TC2000 (1989-2004)
  • Isuzu HVR (2005-2008)
  • Isuzu HTR (2005-2008)
  • Isuzu FTR (2003-2011)
  • Workhorse W24 (2004-2009)
  • Workhorse W25 (2005-2009)
  • GMC T7500 (2004-2009)
  • Chevrolet T7500 (2004-2009)
  • Hino 308 (2005-2008)
  • GMC C7500 Topkick (2003-2009)
  • GMC C6500 Topkick (2003-2009)
  • Chevrolet C7500 Kodiak (2003-2009)
  • Chevrolet C6500 Kodiak (2003-2009)
