WABCO 9254811700 - Air Brake Spring Brake Actuator - Tristop Series, Disc, 24/24
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
WABCO part description
Product Attributes
| Output Force M | 11950 N |
| Max. operating pressure | 147.94 / 123.28 psi |
| Calculated Volume (dm³) | 11.788 |
| Size | 195 x 310 x 195 |
| Return-Spring Force | 220 N |
| Total Length | 253.0 mm |
| Temperature Range | -40°C to +80°C |
| Type | 24/24 |
| Release Pressure | 5.1 bar |
| Opposite | 925 481 171 0 |
| Bolt Lengths | 43.0 mm |
| Stroke | 57/57 mm |
| Type Of Operation | Disc |
| Distance between bolts | 120.6 mm |
| Push-rod thread | Ball R8 |
| Port threads | M16 x 1.5 |
| Push-Rod Length | 15 mm |
| Port thread 11 | M16 x 1.5 JED - 152 |
| Bolt Threads | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 JED - 152 |
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
