WABCO 4123520290 - Air Brake Compressor - Single Cylinder, Flange Mounted, Water Cooling
$96349
MSRP: $1,435.90
Save: $472.41
In stock
limited availability at this price!
. Learn more
WABCO part description
Product Attributes
| Size | 196 x 344 x 342 |
| Max. operating pressure | 12.5 bar |
| Calculated Volume (dm³) | 23.059 |
| Piston stroke | 62 mm |
| Operating speed | 3000 (1/min) |
| Mounting | Flange mounting |
| Port Thread 9.1 | M16 x 1.5 |
| Port Thread 8.1 | M12 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Port Thread 9.2 | M16 x 1.5 |
| Type | Single Cylinder |
| Weight | 33.1861 |
| Piston Diameter | 85 mm |
| Swept Volume (Cm³) | 352 cm3 |
| Lubrication | Lubrication supplied from engine |
| Crankshaft thread | M20 x 1.5 |
| Port thread 2 | M26 x 1.5 |
| Port Thread 0 | Ø 34.9 mm |
| Cooling | Water |
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
