(888) 312-8812 Login SignupRANCHO RS55827 RS5000X Suspension Strut
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RANCHO RS55827 Part Description
Manufacturer
Product Description
RS5000X Suspension Strut
Features & Benefits
- IMPROVED HANDLING AND PERFORMANCE -- Cross Tuned technology featuring exclusive rebound valving system and advanced compression phase improves overall handling and performance on and off road
- MINIMIZES ROUGH RIDE -- Exclusive Progressive Engagement Valving is custom-tuned for each vehicle to help reduce initial impacts at low speeds and minimizes a rough ride
- STRONG AND DURABLE -- Features a nitro-carburized piston rod to resist scuffs & corrosion, double-welded loops at stress areas, application-specific sintered iron piston for enhanced structural integrity and polyvinyl protective boot
- HANDLES EXTREME TEMPERATURE CHANGES -- Large twin-tube body filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248degF
- HANDLES EXTREME TEMPERATURE CHANGES -- Large twin-tube body filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248°F
- SMOOTH PERFORMANCE -- Polyurethane rebound bumper and rubber bushings help absorb ride harshness while the fluon-banded piston enhances responsiveness to changing road conditions for an overall smoother ride
- REDUCES FADE -- Nitrogen gas pressurized to 60 PSI to minimize air-to-oil mixture to reduce damping performance fade and foaming
- MAINTAINS VEHICLE CONTROL -- Compression Control Valve is custom-tuned for each vehicle to regulate fluid transfer to absorb impacts without disc flutter and help maintain shock motion control
- BUILT TO LAST -- Low-friction, self-lubricating seal retains gas and oil for quicker rebound and smoother compression while the application-specific piston delivers heightened control of shock motion due to the expanded piston area
- BUY WITH CONFIDENCE -- Comes with Rancho's Limited Lifetime Warranty
- BUY WITH CONFIDENCE -- Comes with Rancho’s Limited Lifetime Warranty
RANCHO RS55827 Specifications
Product Attributes
| Body Type | SS3 |
| Compressed Length | 10.8 IN |
| Travel Length | 3.83 in |
| Grade Type | Performance |
| Extended Length | 14.63 in |
| Gas Charged | Yes |
| Adjustable Damping | No |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Finish | Painted |
| Hydraulic Lockout | No |
| Lower Mount Type | Loop Bushing Mount - 5/8" Bushing ID X 1.5/16" Bushing OAL |
| Parts Pack(s) | P01614 |
| Upper Mount Type | Loop Bushing Mount - 5/8" Bushing ID X 1.5/16" Bushing OAL |
| Compressed Length | 274.3 MM |
| Extended Length | 371.6 MM |
| Travel Length | 97.3 MM |
| Lower Mount Type | Loop (Eyelet) Bushing |
| Upper Mount Type | Loop (Eyelet) Bushing |
Additional Information
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708801910 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| MSDS Sheet Number | 01164 |
| UPC | 00039703008624 |
| VMRS Code | 016020000 |
| UNSPSC | 25172007 |
RANCHO RS55827 Cross References
| Brand | Part Number |
|---|---|
| AutoZone | TS3332522B |
| Autopart International | 2701248202 |
| FCS | 345419 |
| Gabriel | G51715 |
| KYB | 341600 |
| MONROE | 71358 |
| Monroe Shocks & Struts | 71358 |
| NAPA Shocks | 71358 |
| Nissan | E61109FE0A, E61109FE0B, E61109FE1B, E61109FE4A, E61109FE4B, E6110EZ31B, E6110ZQ00C, E6110ZQ20C, E6110ZR00A, E6110ZR00B, E6110ZR01B, E6110ZR40A, E6110ZR40B, E6110ZR51A, E6110ZZ50A, E6110ZZ50B, E6110ZZ51A, E6110ZZ51B |
| PM Auto | PM6001253 |
| Rancho | RS5827 |
| Sensen | 32140134 |
| Unity Automotive | 215100 |
RANCHO RS55827 Fits Vehicles
- Nissan Pathfinder Armada (2004)
- Nissan Armada (2005-2015)
- INFINITI QX56 (2004-2008)
- Nissan TITAN (2004-2015, 2017-2024)
