(888) 312-8812 Login SignupDELPHI TC2448 Control Arm and Ball Joint Assembly
Tap to view 2 more
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
DELPHI TC2448 Part Description
Manufacturer
Product Description
Control Arm and Ball Joint Assembly
Features & Benefits
- Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Control arms utilize robot welding for consistent performance and quality
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC2448 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Left Lower |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Mounting Type | Press In |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Stamped |
| Control Arm Material | Steel |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 2 |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 3.850 IN |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 0.787 IN |
| Ball Joint Thread Diameter | 20.00 MM |
| Ball Joint Stud Length | 1.004 IN |
| Ball Joint Stud Length | 25.50 MM |
| Control Arm Maximum Length | 19.094 IN |
| Control Arm Maximum Length | 485.00 MM |
| Bushing Material | Rubber |
| Mounting Hole Diameter | 0.472 IN |
| Mounting Hole Diameter | 12.00 MM |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Control Arm Maximum Width | 97.79 MM |
| Thread Diameter | 20.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Thread Diameter | 0.787 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| UPC | 00689604298954 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC2448 Cross References
| Brand | Part Number |
|---|---|
| CORTECO | 49399052, 49395301 |
| DORMAN | 521-625, CB81373, CB81373PR |
| MEVOTECH | CMS101351, CMS101350, CMS251135 |
| MEYLE | 1160500091, 016 010 0015 |
| MOOG | K500113 |
| Mercedes-Benz | 906 330 40 07 |
| N/A | 906 330 46 07, 2E0 407 151 L, 2E0 407 151 M, RK6211966, CMS101350, 521625, A 906 330 40 07, A 906 330 46 07 |
| QUICK STEER | K500113 |
| VAICO | V30-7603 |
DELPHI TC2448 Fits Vehicles
- Freightliner Sprinter 2500 (2007-2020)
- Freightliner Sprinter 3500 (2007-2020)
- Mercedes-Benz Sprinter 1500 (2019-2021)
- Mercedes-Benz Sprinter 3500 (2010-2021)
- Mercedes-Benz Sprinter 2500 (2010-2021)
- Dodge Sprinter 2500 (2007-2009)
- Dodge Sprinter 3500 (2007-2009)
