DELPHI TA5274 Part Description
Manufacturer
Product Description
Tie Rod End
Features & Benefits
- Delphi includes the necessary accessories for a complete job
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Delphi tie rods are fatigue tested to avoid failure
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TA5274 Specifications
Product Attributes
| Position(s) | Outer, Right Outer. For the position specific to your vehicle, refer to the Applications. |
| Item Grade | Standard Replacement |
| Length | 134.00 MM |
| Color | Black |
| End 1 Gender | Male |
| End 2 Gender | Male |
| Pre-Greased | Yes |
| Grease Fitting Included | Yes |
| Dust Boot Included | Yes |
| Width | 40 MM |
| Type | Bent |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 0.687 IN |
| End 2 Thread Diameter | 17.46 MM |
| Height | 78.00 MM |
| Housing Material | Steel |
| Tube Diameter | 0.688 IN |
| Tube Diameter | 17.46 MM |
| Adjustable | No |
| Greaseable | Yes |
| Weight | 0.9 lb |
| Cone Outside Diameter | 13.10 MM |
| Bearing Material | Plastic |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| Stud Type | Threaded |
| Length - Stud Center to End | 4.449 IN |
| Length - Stud Center to End | 113.00 MM |
| Dust Boot Material | Rubber |
| Tie Rod Material | Steel |
| End 2 Threads Per Inch | 18 |
| End 1 Threads Per Inch | 20 |
| End 1 Thread Diameter | 0.437 IN |
| End 1 Thread Diameter | 11.11 MM |
| Shank Length | 13.10 MM |
| Stud Length | 13.10 MM |
| Grade Type | Standard Replacement |
| Grade | Premium |
| Shank Length | 0.516 IN |
| Stud Length | 0.516 IN |
| Cone Outside Diameter | 0.516 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708998180 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604290279 |
| VMRS Code | 015004019 |
| UNSPSC | 25174205 |
DELPHI TA5274 Cross References
| Brand | Part Number |
|---|---|
| DORMAN | TO851038, 534-569, TO851038PR |
| Ford | C5ZZ3A130B, C5ZZ3A130D |
| MAS Industries | 534-569 |
| MEVOTECH | MES336R |
| MOOG Chassis Products | ES336R |
| N/A | MES336R, TO851038, JTE1236, TO851038PR |
DELPHI TA5274 Fits Vehicles
- Mercury Cyclone (1965)
- Mercury Villager (1965)
- Mercury Comet (1965)
- Ford Ranchero (1964-1965)
- Ford Mustang (1964-1966)
- Ford Falcon Sedan Delivery (1963-1965)
- Ford Falcon (1965)
