Name: Rancho RS55326 RS5000X Suspension Shock Absorber
SKU: rs55326
Price: 85.99 USD
Availability: InStock

RANCHO part description

Product Description

RS5000X Suspension Shock Absorber

Features & Benefits

IMPROVED HANDLING AND PERFORMANCE -- Cross Tuned technology featuring exclusive rebound valving system and advanced compression phase improves overall handling and performance on and off road
MINIMIZES ROUGH RIDE -- Exclusive Progressive Engagement Valving is custom-tuned for each vehicle to help reduce initial impacts at low speeds and minimizes a rough ride
STRONG AND DURABLE -- Features a 16mm nitro-carburized piston rod to resist scuffs & corrosion, double-welded loops at stress areas, 35mm sintered iron piston for enhanced structural integrity and polyvinyl protective boot
HANDLES EXTREME TEMPERATURE CHANGES -- Large twin-tube body filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248degF
HANDLES EXTREME TEMPERATURE CHANGES -- Large twin-tube body filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248°F
SMOOTH PERFORMANCE -- Polyurethane rebound bumper and rubber bushings help absorb ride harshness while the fluon-banded piston enhances responsiveness to changing road conditions for an overall smoother ride
REDUCES FADE -- Nitrogen gas pressurized to 150 PSI to minimize air-to-oil mixture to reduce damping performance fade and foaming
MAINTAINS VEHICLE CONTROL -- Compression Control Valve is custom-tuned for each vehicle to regulate fluid transfer to absorb impacts without disc flutter and help maintain shock motion control
BUILT TO LAST -- Low-friction, self-lubricating seal retains gas and oil for quicker rebound and smoother compression while the application-specific piston delivers heightened control of shock motion due to the expanded piston area
BUY WITH CONFIDENCE -- Comes with Rancho's Limited Lifetime Warranty
BUY WITH CONFIDENCE -- Comes with Rancho’s Limited Lifetime Warranty

Product Attributes

Compressed Length	13.85 IN
Travel Length	7.9 in
Finish	Painted
Grade Type	Performance
Extended Length	21.75 in
Gas Charged	Yes
Adjustable Damping	No
Dust Shield Included	Yes
9783	No
9789	S51
9791	LS38
9792	No
9801	35 MM
9908	No
Body Diameter	2.18
Lower Mount Type	Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 1.1/2" Sleeve OAL
Part Description	Shock Absorber
Parts Pack(s)	P01167
Compressed Length	351.8 MM
Extended Length	552.5 MM
Travel Length	200.7 MM
Shock Stroke	7.9 IN
Shock Stroke	200.7 MM
Lower Mount Code	LS38
Upper Mount Type	Stem Mount - 2 5/8" Stem Length X 1/2"-13 Thread Pitch
Upper Mount Code	S51
Shock Absorber Rod End Measuring Point	Center of Loop
Shock Absorber Body End Measuring Point	Base of Stem
Mounting Hardware Included	Yes
Body Diameter	2.25 IN
Body Diameter	57.2 MM
Cylinder Outside Diameter	2.25 IN
Cylinder Outside Diameter	57.2 MM
Body Material	Steel
Cylinder Material	Steel
Body Color	White
Cylinder Color	White
Color	White
10531	Painted
Boot Included	Yes
9786	2.99 IN
9786	75.9 MM
Dust Shield Material	Rubber
Dust Shield Color	Red
1183	0.622 IN
1183	15.8 MM
Shaft Material	Nitrocarburized
Shock Absorber Bore Size	1.3779527559055118 IN
Internal Rebound Spring	No
Type	Telescopic
10530	Passive
10527	No
Adjustable Rebound	No
10526	Progressive
10529	No
10528	No
10534	0 IN
10535	0 IN
Air Adjustable	No
Air Ride Suspension	No
9615	No
9620	No
9618	No
New Or Remanufactured	New
Coil Over Springs Included	No
Bearing Plate Included	No
Spring Included	No
9621	No
Spring Isolators Included	No
Spring Seat Included	No
9476	No
9619	No
Adjustable Damping	No
Internal Construction Type	Twin Tube

Additional Information

Country of Origin (Primary)	US
Canadian Harmonizing Tariff Code	8708803000
Harmonized Tariff Code (Schedule B)	8708801600
Harmonized Tariff Code (HTS)	8708801600
MSDS Sheet Number	01164
UPC	00039703006088
VMRS Code	016008003
UNSPSC	25172011
