MSD 72223 Part Description
Manufacturer
Product Description
MSD Black 7AL-2 Ignition Control
Features & Benefits
- 6 Amps Per 6,000 RPM; 12 Amps at 12,000 RPM
- Built-in 2-step rev control
- Supplied with 3000, 7000, 8000, 9000 RPM Chips
- Terminal strips for convenient hookup
- 12-18 Volts, Negative Ground
- Diagnostic Troubleshooting LED
- Operates on 4, 6 or 8-cylinder engines
- 14,000 RPM with 14.4 Volts
MSD 72223 Specifications
Product Attributes
| Brand | MSD |
| Category | Ignition |
| Color | Black |
| Connector Gender | Terminal Strip |
| Connector Quantity | 2 |
| Current Draw | 12,000 RPM |
| Emission Code | 4 |
| Features | Rev Limiter |
| Grade Type | Race |
| Height | 5.75 IN |
| Ignition Type | Performance |
| Length | 8.25 IN |
| Maximum RPM | 14,000 RPM |
| Mount Type | Surface Mount |
| Mounting Hardware Included | Yes |
| Primary Voltage | 570 |
| Product Type | Ignition Box |
| Secondary Voltage | 47,000 RPM |
| Spark Energy (mJ per spark) | 160 |
| Sub Category | Control Modules |
| Terminal Gender | Terminal Strip |
| Terminal Quantity | 10 |
| Voltage Required | 12-18 |
| Warning | California Proposition 65 |
| Warranty | Manufacturer's Limited 1 Year Warranty |
| Weight and Size | 4.85 lbs., 8.25L x 3.75W x 5.75H |
| Width | 3.75 IN |
Additional Information
| Original Supplier | US |
| Warranty Special | Manufacturer's Limited 1 Year Warranty |
| Warranty Special UOM | TX |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8511804000 |
| Harmonized Tariff Code (HTS) | 8409915085 |
| NAFTA Preference Criterion Code | B |
| UPC | 00085132722235 |
